- Page 1 Design Guide with Installation Instructions 36” Built-In Bottom Freezer Refrigerators Pub. No. 49-60706-1 Part No. 224D3735P001 03-14 GE monogram.com...
-
Page 2: Table Of Contents
• Les réparations doivent être faites par un technicien qualifié. À cause du poids et de la taille de ce réfrigérator et pour réduire le risque de blessure et de dommages, IL For Monogram local service in your area, call FAUT TROIS PERSONNES POUR FAIRE L’INSTALLATION 1.800.444.1845. CORRECTEMENT. -
Page 3: The Installation Space
Design Guide DIMENSIONS AND CLEARANCES THE INSTALLATION SPACE 35-1/2" 25-3/8" Framed Models 35" Finished Width 25-3/4" Stainless Steel Models Case Width The finished Case Depth Wall View 2-5/16" * Shipping height. The cutout width refrigerator can be must be adjusted to fit into a 6"... -
Page 4: 130° Door Swing
Design Guide Frameless Cabinets: The case trim overlaps cabinets at the top and sides. Therefore, frameless cabinets Refrigerator may require filler strips to prevent 23-7/8" From interference with cabinet door swing. Rear of The opening must allow for filler strips. Refrigerator 1"... -
Page 5: 90° Door Swing
Design Guide Frameless Cabinets: The case trim overlaps cabinets at the top and Refrigerator sides. Therefore, frameless cabinets may require Case Trim filler strips to prevent interference with cabinet door swing. The opening must allow for filler strips. 23-7/8" From Rear of Refrigerator 1/4"... -
Page 6: Customization Basics
Stainless Steel Wrapped Refrigerators Stainless steel wrapped refrigerators with beveled edges and tubular stainless steel handles that coordinate with other Monogram appliances. These models are shipped ready for installation. Trimmed Refrigerators Trimmed refrigerators are designed to be customized with decorative panels. -
Page 7: Panel Dimensions
Design Guide 1/4” FRAMED PANEL DIMENSIONS 5/16" Trim If you choose to install framed panels, they must be cut Door Reveal to the dimensions shown. The panels will slide into the frame on the door, drawer and grille. 1/4" If the custom panel is less than 1/4” thick and if it fits Panel loosely in the door frame, it can be backed up with a piece of filler material or foam tape to improve the fit. -
Page 8: Side Panels
Design Guide SIDE PANELS ZUG2 GRILLE PANEL DIMENSIONS Side panels must be used whenever the sides of the The ZUG2 unified grille panel kit provides for the refrigerator will be exposed. The 1/4 ” side panels will installation of a framed or overlay grille panel. slip into the side case trim. -
Page 9: Installation Instructions
Installation Instructions TOOLS REQUIRED MATERIALS REQUIRED • Tinsnips to cut banding • 35” long 2x4 for Anti-Tip support • Stepladder • 1/4” copper water line tubing or GE SmartConnect ™ • Bucket Refrigerator Tubing kits • Level • Water shut-off valve •... -
Page 10: Step 1 Remove Packaging
Installation Instructions CAUTION: STEP 1 REMOVE PACKAGING DO NOT ATTEMPT TO ROLL UNIT OFF CAUTION: SKID. Refrigerator is much heavier at the PRUDENCE: using a hand truck, handle from side only. IL NE Remove 5 FAUT PAS ESSAYER DE FAIRE base channel PRUDENCE: ROULER LE RÉFRIGÉRATEUR... -
Page 11: Step 2A, Ro Water Line
Installation Instructions STEP 3 INSTALL SIDE PANELS Skip this step when not using side panels If you are using 1/4” side panels, they should be inserted into the case trim. Fasten the panels to the refrigerator with stick-on hook and loop fastener strips before setting refrigerator in place. - Page 12 Installation Instructions STEP 4 INSTALL ANTI-TIP BRACKET (cont.) Install Wall Toggles: • Insert the bolts into the toggle by hand until snug. The wall toggles and bolts can be ordered as Service Kit Tighten with a wrench. #WR49X10193. Wall toggles are installed in the drywall and metal studs for stability.
-
Page 13: Step 5, Level Refrigerator
Installation Instructions STEP 5 LEVEL REFRIGERATOR STEP 6 SECURE UNIT TO WALL All models have 4-point leveling. The front is supported • The “L” rod can be found in the upper left corner of by leveling legs, the rear is supported by adjustable the unit in the access compartment. -
Page 14: Step 8, Install Grille Panel
Installation Instructions STEP 7 ADJUST DOOR SWING STEP 8 INSTALL GRILLE PANEL NOTE: This refrigerator has a 2-position door stop. • Raise the grille panel to stop position. When space does not allow the door to swing open fully to 130°, you may change the door swing to a 90° opening. -
Page 15: Step 9, Install Framed Panels
Installation Instructions STEP 9 INSTALL 1/4” FRAMED PANELS Right hand models shown. Use the same instructions for left hand models. IF YOU ARE INSTALLING OVERLAY PANELS, GO TO STEP 9A. Standard supplied handle shown in 1/4” panel position. Install door and drawer panels: •... -
Page 16: Step 9A Install Overlay Panels
Installation Instructions STEP 9A INSTALL OVERLAY PANELS Right hand models shown. Use the same instructions for left hand models. Use Front Hol to Secure Hand Use Rear Holes to Secure Trim Supplied handle shown in the overlay panel position. Install door and drawer panels: •... -
Page 17: Step 10 Connect Water Supply
Installation Instructions STEP 10 CONNECT WATER SUPPLY STEP 11 CONNECT POWER • Check to be sure the power cord is plugged into the receptacle. House Refrigerator Water Supply Water Supply • Check to make sure power to refrigerator is on by opening refrigerator door to see if interior lights are on. -
Page 18: Step 13 Install Toekick
Installation Instructions STEP 13 INSTALL TOEKICK • Locate the supplied toekick (shipped taped to the side of the refrigerator). Install the toekick assembly with the 3 screws provided, adjust to the desired height and tighten the screws. • A custom toekick can be installed to match or complement the surrounding cabinetry. - Page 19 Notes...
- Page 20 NOTE: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram local service in your area, call ® 1.800.444.1845. NOTE: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice.
