Step 2
• Cut a piece of corrugated to use as a pad to protect
Match
handle
extrusions
• Place custom panels on the pad, appearance side
to handle
FOR CUSTOM
Fresh food door:
WOOD
• On the back side of the panel - at the handle side,
PANELS
See Step 2A
for Stainless
• Slip panels into new extrusion on the handle side of
Steel panels
• Align the extrusion at the pencil mark, 1/4" below the
• Tape the extrusion to the panel to prevent movement.
• Center punch and drill 1/8" pilot holes through the
• Turn panel over. On the appearance side, use 9/32" bit
Freezer drawer:
• Lay panel on the pad, appearance side down.
• Slip panel into the new extrusion on the handle end.
• The panel should be even with both ends of the
• Center punch and drill 1/8" pilot holes through the
• Turn panel over. On the appearance side, use 9/32" bit
CAUTION: Hole locations must be exact to accept handle
standoff and handle assembly.
the panel finish. Use 1/2" thick section of plywood to
protect flooring when drilling.
down.
measure and mark 1/4" below the top edge of the
panel with a pencil.
the panels.
top of the panel.
holes in the extrusion and into the panel.
to enlarge clearance hole.
extrusion. Tape panel to extrusion to prevent
movement.
holes in the extrusion and into the panel.
to enlarge clearance hole.
ZKHCSS1 Trim Kit (For 1/4" Panels)
Tubular Stainless Steel Handles
Freezer Panel
Decorator
Door
Panel
Back
Side
Fresh
Food
Panel
Back Side
Extrusion
33
