Step 1
Temporarily
mount door
panels
Fresh food door:
• Place the prepared 3/4" custom door panels on the
• Push the panel back against the steel door, making
• Secure the panel to the trim temporarily by driving 2
• Slide the handle extrusion in between the panel and
• Temporarily secure the extrusion to the door with 2
Note: The freezer drawer door should be removed as shown
in the installation instructions for the ZKTC36 kit. Follow the
instructions in Step 1 to remove the door.
Freezer drawer:
• Place the prepared 3/4" custom panel on the bottom
• Secure the panel to the trim temporarily by driving one
• Temporarily mount the assembled drawer door onto the
Caution: Be careful not to bend light switch plate on the
bottom of the door.
• Slide the handle extrusion in between the panel and
• Temporarily secure the extrusion to the door with 2
bottom trim with support bracket tabs inserted into trim
slots.
sure the panel is flush with the hinge side trim.
screws through the backside of the trim at the top.
steel door.
screws.
trim with support bracket tabs inserted into the trim
slots. The panel should be flush with trim on both sides.
screw through the back side of each side trim.
drawer slides. This will help to determine the handle
location.
steel door.
screws.
ZKHTC1 Trim Kit (For 3/4" Panels)
Support for Custom Handles
Insert support bracket tabs
into slots on bottom trim
Inside Freezer Drawer
Install
2 Screws
