Step 7
Check to be sure that refrigerator power cord is not
Connect
plugged into the wall outlet.
Water
Supply
• Locate and bring copper tubing to the front of the
cabinet.
• The copper tubing should be just long enough to
reach the coupling. Excess tubing length could interfer
with drawer closing or toekick installation.
• Slip a 1/4-1/4 union nut (provided) over both ends of
the copper tubing at the right front leg of the refrigera-
tor and couple the lines.
• Turn on the water to check for leaks.
Step 8
If you are using 3/4" thick custom panels, SKIP THIS
Install 1/4"
STEP. See Custom Panel Dimensions pages for panel
door panels
sizes with ZKTC36L or ZKTC36R trim kit and other kits.
Refer to trim kit installation instructions in this booklet.
Fresh food door panel:
• Open door to 90° stop. Remove the Phillips head
• Remove handle. Retain all screws.
• Slide custom panel into the door trim.
• Replace door handles and secure with original
Freezer drawer panel:
• Slide freezer drawer out about half way.
• Remove the Phillips head screws from the aluminum
• Lift off handle. Retain screws.
• Slide custom panel into
• Replace the drawer handle
screws from the aluminum trim door handle.
screws.
trim door handle.
the drawer trim.
and secure with
original screws.
Installation
36" Bottom Mount Refrigerator
Remove
4 Screws
Install
Original
Screws
