Specifications - Icom IC-F8100 Instruction Manual

D General
• Frequency coverage :
Receive 0.5–29.9999
Transmit 1.6–29.9999
• Type of emission : J3E (USB/LSB), A1A (CW),
A3E (AM), F1B (FSK)
(depends on version)
• No. of memory Ch. : 500 channels (max.)
• Usable temp. range : –30˚C to +60˚C
• Frequency stability : ±0.3 ppm (–30˚C to +60˚C)
• Power supply : 13.8 V DC
(11.73–15.87 V DC)
• Current drain :
Transmit (typical) at max. power 28 A
Receive at max. audio
• Dimensions (projections not incl.):
Main/Front package 62(W)×174(H)×259(D) mm
• Weight (approx.) :
Main/Front package 3.8 kg
D Transceiver
• Output power : (typical)
J3E/A1A HIGH 125 W p-p
MID
LOW
A3E HIGH 30 W Carrier
MID
LOW
J3E/A1A HIGH 75 W p-p
MID
LOW
• Spurious emission : 64 dB (typical)
below peak output power
• Carrier suppression : 50 dB
below peak output power
• Unwanted sideband suppression :
400 Hz 55 dB
below peak output power
1 kHz 65 dB
below peak output power
All stated specifications are typical and subject to change without notice or obligation.
(Unit: MHz)
(negative ground)
3.0 A
50 W p-p
10 W p-p
12.5 W Carrier
3 W Carrier
50 W p-p
10 W p-p

SPECIFICATIONS

D Receiver
• Sensitivity:
J3E (Pre Amp ON)
(0.5–1.5999 MHz) 14 dBµV
(1.6–29.9999 MHz) –14 dBµV
A3E
(0.5–1.5999 MHz) 22 dBµV
(1.6–29.9999 MHz) 6 dBµV
• Spurious response rejection ratio:
More than 70 dB
• AF output power :
(at 13.8 V DC)
More than 4.0 W at 10%
distortion with a 4 Ω load
• Clarifier range : ±200 Hz
8
(10 dB S/N)
(10 dB S/N)
(10 dB S/N)
(10 dB S/N)
