9

OPTIONS

AT-140
automatic antenna tuner
Antenna and control cable receptacles
for easy installation and tuner through
function are available.
OPC-2142
shielded control cable
OPC-2151
shielded control cable
Shielded control cable protects the trans-
ceiver from RF feedback and extends the
separation between AT-140 and trans-
ceiver up to 10 m.
OPC-2142: 4 pin, OPC-2151: 6 pin
OPC-2143
shielded control cable
Shielded control cable protects the trans-
ceiver from RF feedback and extends the
separation between AT230 and trans-
ceiver up to 5 m.
AD-119
junction box
Allows you to connect the AT-140, AT230
external modem or PC.
Recommended Automatic tuning antenna, AT230 from Moonraker Australia Pty. Limited
The AT230 is a 2.6 m length mobile whip antenna with automatic tuning function. The antenna
matches 2–30 MHz continuously. Use the optional OPC-2143 cable for use with the IC-F8100.
Ask your dealer for details.
54
SP-10
external speaker
SP-25
external speaker
SP-30
external speaker
The SP-25 is same as that supplied with
the IC-F8100. Mounting bracket is sup-
plied with the speaker.
Max. AF input/impedance: 5 W/4 Ω
HM-193
hand microphone
Same as supplied with the IC-F8100 #01
(One package type) or #02 (Separation
Type).
HM-192
command mic microphone
Same as supplied with the IC-F8100 #03
(Command MIC type).
Allows you to remotely control the trans-
ceiver by the microphone. The HM-193
requires one of the separation cable,
OPC-607, OPC-608, OPC-609 or OPC-
726.
MB-126
mounting bracket
CFU-F8100
cooling fan
RMK-6
separation kit
Same as supplied with the IC-F8100 #02
(Separation Type).
Allows you to separately install the trans-
ceiver Front panel from the Main unit for
operating convenience. The RMK-6 re-
quires one of the separation cable, OPC-
607, OPC-608, OPC-609 or OPC-726.
OPC-607/OPC-608/OPC-609/OPC-726
separation cable
OPC-607 : 3 m
OPC-608 : 8 m
OPC-609 : 1.9 m
OPC-726 : 5 m
