  • Page 1 HF TRANSCEIVER S-15005XZ-C1 August 2013...
  • Page 2 8. READ the instructions of the test equipment thoroughly before connecting it to the transceiver. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION SPECIFICATIONS SECTION INSIDE VIEWS SECTION DISASSEMBLY INSTRUCTION SECTION CIRCUIT DESCRIPITON RECEIVER CIRCUITS ..................4-1 TRANSMITTER CIRCUITS ................4-2 FREQUENCY SYNTHESIZER CIRCUITS ............4-4 VOLTAGE BLOCK DIAGRAM ................4-4 PORT ALLOCATIONS ..................4-5 SECTION ADJUSTMENT PROCEDURES PREPARATION ....................5-1 FREQUENCY ADJUSTMENT ................

  • Page 4: Section 1 Specifications

    SECTION 1. SPECIFICATIONS M General M Transmitter • Frequency coverage: • Output power (typical): Receive 0.5–29.9999 MHz AUS versions Transmit 1.6–29.9999 MHz HIGH 100 W p-p 50 W p-p • Mode: 10 W p-p AUS versions J3E (USB), A3E (AM; RX only) Other versions Other versions J3E (USB/LSB),...

  • Page 5: Section 2 Inside Views

    SECTION 2. INSIDE VIEWS • DISPLAY UNIT LCD DIMMER CONTROLLER (Q6301) MIC ALC AMP (IC6005) LCD DIMMER CONTROLLER (Q6302) RESET IC (IC6001) FRONT CPU CLOCK (X6001) FRONT CPU (IC6004) LEVEL CONVERTER (IC6012) LCD DIMMER CONTROLLER +8 V REGULATOR (IC6010) (IC6009) +3 V REGULATOR (IC6007) +5 V REGULATOR...
  • Page 6 • MAIN UNIT YGR AMP (IC1101) SRAM (IC1812) RF AMP (IC1703) (Q1116) RF AMP MAIN CPU (Q1117) (IC1806) 1/2 PRESCALER (IC1603) R8 LINE CONTROLLER (IC1804) D/A CONVERTER 1ST TX IF BUFFER (IC1815) (Q1401) LEVEL CONVERTER (IC1817) 1ST TX IF MIXER LEVEL CONVERTER (IC1401) (IC1818)
  • Page 7 • PA UNIT BIAS CONTROLLER RF AMP (for POWER AMP) (Q4002) (IC4002) PRE-DRIVE AMP (Q4003) COOLING FAN DRIVER (Q4001) SERIAL TO PARALLE CONVERTER COOLING FAN DRIVER (IC5001) (Q4008) POWER DIVIDER VARISTOR-2 UNIT (L4009) VARISTOR-1 UNIT POWER AMP (Q4006) POWER AMP (Q4007) POWER COMBINER (L4014)
  • Page 8 • DSP-1 UNIT CLOCK GENERATOR (IC3610) D/A CONVERTER CODEC (IC3613) (IC3611) A/D CONVERTER (IC3608) BUFFER BUFFER (IC3607) (IC3605) BUFFER (IC3604) BUFFER (IC3614) BUFFER (IC3615) BUFFER (IC3603) (IC3003) AGC LIMITTER (IC3617) AF MUTE SW BUFFER (IC3602) (IC3005) AF AMP BUFFER (IC3001) (IC3601) ELECTRONIC VOLUME (IC3008)
  • Page 9 • DSP-2 UNIT +1.2 V REGULATOR (IC8203) (IC8201) RESET IC (IC8205) RESET IC (IC8204) AF SW AF SW (IC8217) (IC8216) USB HUB (IC8207) USB BRIDGE (IC8209) USB BRIDGE (IC8210) +3.3 V REGURATOR (IC8215) USB CODEC (IC8208)

  • Page 10: Section 3 Disassembly Instruction

    SECTION 3. DISASSEMBLY INSTRUCTION 1. Removing the DISPLAY UNIT 2. Removing the MAIN UNIT 1) Remove 4 hex socket screws from the FRONT 1) Remove 4 screws from the top cover, and then PANEL, and then separate it from the CHASSIS. remove it.
  • Page 11 3. Removing the DSP-1 and DSP-2 UNITs 4. Removing the DRIVER UNIT 1) Remove the 4 screws from the bottom cover, and 1) Cut the cable tie and remove it. then remove it. MP45 Screw ×4 8950000180 CABLE TIE-80 Cable tie Bottom cover CHASSIS 2) Remove 3 screws, and then remove the PA case.
  • Page 12 5. Removing the PA UNIT 1) Remove the 15 screws from the PA UNIT. 2) Disconnect the 2 flat cables and 2 coaxial cables from the PA UNIT. 3) Remove the PA UNIT from the CHASSIS in the direction of the arrow. FLAT CABLE Screw ×15...

  • Page 13: Receiver Circuits

    SECTION CIRCUIT DESCRIPTION 4-1 RECEIVER CIRCUITS 1ST RX IF CIRCUIT (MAIN UNIT) The RX signal from the preamplifier circuit is applied to the RF CIRCUIT (PA AND MAIN UNITS) 1st RX IF mixer (Q1404–Q1407) to be mixed with the 1st The RX signal from the antenna is passed through the RX LO signal, resulting in the 64.455 MHz 1st RX IF signal.

  • Page 14: Transmitter Circuits

    DEMODULATOR CIRCUIT (DSP-1 UNIT) The demodulated signal is applied to the CODEC (IC3611) The 3rd RX IF signal from the 3rd RX IF circuits is passed to be converted into analog AF signal. The AF signal is through the buffer (IC3602, IC3603), and then applied to the passed through the buffer (IC3615), LPF (IC3003) and AF A/D converter to be converted into digital audio signal.
  • Page 15 2ND TX IF CIRCUIT (MAIN UNIT) FILTER CIRCUIT (MAIN UNIT) The 2nd TX IF signal from the 3rd TX IF circuits is applied The TX signal from the 1st TX IF circuits is passed through to the 2nd TX IF mixer (D1812, D1813), to be mixed with the one of BPFs, depending on the operating frequency, to the 2nd TX LO signal, resulting in the 64.455 MHz 1st TX IF remove unwanted signals contained in the TX signal.

  • Page 16: Frequency Synthesizer Circuits

    4-3 FREQUENCY SYNTHESIZER CIRCUITS The 3rd TX/RX LO signal (MAIN UNIT) The 1st TX/RX LO signal The 32 MHz reference frequency signal, which is gener- The 32 MHz reference frequency signal, which is gener- ated by X1601, is amplified by the buffer (Q1601) and two ated by X1601, is amplified by the buffer (Q1601) and AMPs (IC1604 and IC1605), and then applied to the divider AMP (IC1604), and then applied to the BPF (L1608,...

  • Page 17: Port Allocations

    4-4 PORT ALLOCATIONS • FRONT CPU (DISPLAY UNIT: IC6004) Line Line Description Description Name Name LEDC LCD dimmer control. [# A a /MNGR] input. SCNK L=Pushed. CPU reset. RESET L=The CPU is reset. TEMP LCD temperature sensing voltage. L-bus communication line to the MAIN CPU. MICL MIC input level sensing voltage.

  • Page 18: Voltage Diagrams

    4-4 PORT ALLOCATIONS (Continued) • MAIN CPU (MAIN UNIT: IC1806) Line Description Name Binar y to decimal conver ter control. STBSEL_D H=Enabled. Binar y to decimal conver ter control. STBSEL_C H=Enabled. Binar y to decimal conver ter control. STBSEL_B H=Enabled. 4-5 VOLTAGE DIAGRAMS Voltage from the power supply is routed throughout the transponder via regulators and switches.

  • Page 19: Preparation

    SECTION 5. ADJUSTMENT PROCEDURE 5-1 PREPARATION M REQUIRED EQUIPMENTS EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE Frequency range : 0.1–50 MHz CS-F8100 CLONING SOFTWARE Standard signal Cloning software Output level : –20 dBµ to 90 dBµ (Revision 1.0 or later) generator (SSG) (–127 to –17 dBm) Measuring range...
  • Page 20 M ADJUSTMENT CHANNELS Before starting the adjustments, use the cloning software to create the same cloning fi le as shown below, then upload it into the transceiver. CONVENIENT: The cloning data fi le for the adjustment, as described in this service manual, is attached. Right click the clip icon, and select “Save Embeded File to Disk.”...
  • Page 21 M ENTERING ADJUSTMENT MODE 1) Turn OFF the transceiver power, if the transceiver is powered ON. ] to turn ON the transceiver power . 2) While holding down [#], [ ], [ ] and [ ], push [ • The login screen appears as below. 3) Enter “SX-3500,”...
  • Page 22 5-2 RECIEVE ADJUSTMENTS • Select the item using [ ]/[ ], and then set or modify the value as specifi ed, using [ ]/[ TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE ITEM CONDITION 1 • Channel: • Set the preset values. "SSB SQL" "0"...
  • Page 23 5-2 RECIEVE ADJUSTMENTS (Continued) • Select the item using [ ]/[ ], and then set or modify the value as specifi ed, using [ ]/[ ADJUSTMENT TRANSCEIVER’S ADJUSTMENT OPERATION VALUE ITEM CONDITION RF GAIN 1 • Channel: 1) Connect an SSG to the antenna Set this AF •...
  • Page 24 5-3 TRANSMIT ADJUSTMENTS • Select the item using [ ]/[ ], and then set or modify the value as specifi ed, using [ ]/[ TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE CONDITION ITEM NOTE: Start this adjustment after the transceiver is cooled. REFERENCE FREQUENCY 1 •...

  • Page 25: Transmit Adjustment

    5-3 TRANSMIT ADJUSTMENTS (Continued) • Select the item using [ ]/[ ], and then set or modify the value as specifi ed, using [ ]/[ TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE CONDITION ITEM 1 • Channel: 8 • Connect an RF power meter "MID"...
  • Page 26 5-3 TRANSMIT ADJUSTMENTS (Continued) • Select the item using [ ]/[ ], and then set or modify the value as specifi ed, using [ ]/[ TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE CONDITION ITEM TX IF 1 • Channel: 9 1) Connect an RF power meter "HIGH"...
  • Page 27 5-3 TRANSMIT ADJUSTMENTS (Continued) • Select the item using [ ]/[ ], and then set or modify the value as specifi ed, using [ ]/[ TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE CONDITION ITEM 1 • Channel: 11 1) Connect an RF power meter (CONFIG Menu)* "RF Power"...
  • Page 28 5-3 TRANSMIT ADJUSTMENTS (Continued) • Select the item using [ ]/[ ], and then set or modify the value as specifi ed, using [ ]/[ TRANSCEIVER’S ADJUSTMENT ADJUSTMENT OPERATION VALUE CONDITION ITEM TX POWER 1 • Channel: 12 • Connect an RF power meter (CW mode) •...

  • Page 29: Section 6 Parts List

    SECTION 6. PARTS LIST [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION IC1102 1110004050 S.IC NJM3404AV-TE1-#FMZB 112.7/78.5 D1118 1790001621 S.DIO 1SV308(TPL3F) 18.3/47.8 IC1103 1110004050 S.IC NJM3404AV-TE1-#FMZB 124.4/78.4 D1119 1790001621 S.DIO 1SV308(TPL3F) 23.8/95.8 IC1104 1130011760 S.IC CD4094BPWR 94.0/31.4 D1120 1790001621 S.DIO 1SV308(TPL3F) 36.5/42.2...
  • Page 30 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION L1127 6200003121 S.COI NLV32T-8R2J 27.9/91.8 L1621 6200005011 S.COI NLV25T-100J 56.6/68.4 L1129 6200010830 S.COI C2520C-3R3G-A 27.8/67.4 L1622 6200002431 S.COI NLV25T-082J 88.2/59.3 L1130 6200010810 S.COI C2520C-2R2G-A 27.8/75.5 L1623 6200002431 S.COI NLV25T-082J 85.2/59.9 L1131 6200010950 S.COI C2520C-1R5G-A (1.5U)
  • Page 31 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R1140 7030003320 S.RES ERJ3GEYJ 101 V (100) 36.6/77.0 R1452 7030003640 S.RES ERJ3GEYJ 473 V (47K) 115.8/19.3 R1141 7030003320 S.RES ERJ3GEYJ 101 V (100) 36.4/61.1 R1453 7030003440 S.RES ERJ3GEYJ 102 V (1K) 129.0/69.2 R1142 7030003320 S.RES ERJ3GEYJ 101 V (100)
  • Page 32 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R1702 7030005120 S.RES ERJ2GEJ 102 X (1K) 99.5/32.1 R1898 7030003720 S.RES ERJ3GEYJ 224 V (220K) 49.6/20.1 R1705 7030005120 S.RES ERJ2GEJ 102 X (1K) 73.6/13.8 R1899 7030003720 S.RES ERJ3GEYJ 224 V (220K) 30.7/20.1 R1707 7030005240 S.RES ERJ2GEJ 473 X (47K)
  • Page 33 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C1103 4030018980 S.CER C1608 JB 1H 104K-T 3.4/50.3 C1219 4030007020 S.CER C1608 CH 1H 120J-T 35.1/101.8 C1104 4030018980 S.CER C1608 JB 1H 104K-T 7.0/82.1 C1220 4030018600 S.CER C1608 CH 1H 152J-T 30.2/43.4 C1105 4030018980 S.CER C1608 JB 1H 104K-T...
  • Page 34 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C1432 4030007090 S.CER C1608 CH 1H 470J-T 90.5/106.7 C1541 4030019460 S.CER C1608 JB 0J 106M-T 143.7/17.6 C1433 4030017650 S.CER C1005 CH 1H 270J-T 101.3/97.5 C1543 4030018980 S.CER C1608 JB 1H 104K-T 110.6/44.2 C1434 4030007080 S.CER C1608 CH 1H 390J-T...
  • Page 35 [MAIN UNIT] [MAIN UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C1726 4030017780 S.CER C1005 JB 1H 472K-T 42.0/39.6 C1856 4030019990 S.CER C1005 JB 1C 104K-T 46.1/5.2 C1727 4030019990 S.CER C1005 JB 1C 104K-T 64.4/35.9 C1857 4550007220 S.TAN F931A476MCMBMA 58.9/25.6 C1729 4030017500 S.CER C1005 CH 1H 560J-T 46.5/80.1 C1858...
  • Page 36 [MAIN UNIT] [PA UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION EP1706 6910012350 S.BEA MMZ1608Y 102BT 55.0/35.6 IC4001 1180001252 S.IC TA7808F(TE16L1NQ) 52.5/135.6 EP1707 6910012350 S.BEA MMZ1608Y 102BT 64.8/33.5 IC4002 1110003800 S.IC NJM2904V-TE1-#FMZB 75.8/118.5 EP1708 6910012350 S.BEA MMZ1608Y 102BT 62.9/75.8 IC4003 1110003800 S.IC NJM2904V-TE1-#FMZB 77.5/128.7 EP1801 6910013310 S.BEA...
  • Page 37 [PA UNIT] [PA UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION L5111 6200005051 S.COI NLV25T-330J 92.1/20.4 R5108 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) 127.4/132.6 L5112 6200005051 S.COI NLV25T-330J 142.5/17.1 R5109 7030003390 S.RES ERJ3GEYJ 391 V (390) 127.1/133.8 L5121 6200005051 S.COI NLV25T-330J 92.1/44.3 R5110 7030003390 S.RES ERJ3GEYJ 391 V (390)
  • Page 38 [PA UNIT] [PA UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C4124 4030006900 S.CER C1608 JB 1H 103K-T 122.4/134.6 C5272 4030020820 S.CER GRM31A5C2J121JW01D 132.8/23.9 C5001 4030021380 S.CER C5750 JB 2E 684MT 89.0/128.6 C5274 4030020800 S.CER GRM31A5C2J680JW01D 133.8/27.6 C5011 4030011600 S.CER C1608 JB 1E 104K-T 89.0/17.5 C5275 4030018480 S.CER GRM31A5C2J221JW01D...
  • Page 39 [PA UNIT] [DRIVER UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION EP4005 6910020710 E.O OT-047 M3 Q6851 1590003061 S.FET PD55015-E 9.7/20.0 EP5002 6910018930 S.BEA MPZ2012S601A 125.3/130.7 R6851 7030010480 S.RES ERJ1TYJ 181U (180) 8.2/13.1 R6852 7030000020 S.RES MCR10EZHJ 1 (010) 2.0/15.4 C6851 4030004750 S.CER C2012 JB 1H 103K-T 14.1/14.1 Eqv.= This component is equivalent to the REF No.
  • Page 40 [VARISTOR-1 UNIT] [VARISTOR-2 UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION D6431 1750000940 S.DIO 1SS400 TE61 3.5/13.4 D6431 1750000940 S.DIO 1SS400 TE61 3.5/13.4 C6431 4030008920 S.CER C1608 JB 1H 473K-T 3.7/11.7 C6431 4030008920 S.CER C1608 JB 1H 473K-T 3.7/11.7 Eqv.= This component is equivalent to the REF No. component listed above, and M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side) may be substituted on parts orders and repairs.
  • Page 41 [DSP-1 UNIT] [DSP-1 UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION IC3001 1110003800 S.IC NJM2904V-TE1-#FMZB 63.0/22.7 R3056 7030005120 S.RES ERJ2GEJ 102 X (1K) 66.6/31.6 IC3003 1110008270 S.IC AD8692ARMZ-R7 <FE> 54.6/35.9 R3057 7030010040 S.RES ERJ2GEJ-JPW 85.0/19.0 IC3004 1110008270 S.IC AD8692ARMZ-R7 <FE> 87.3/16.3 R3066 7030005040 S.RES ERJ2GEJ 472 X (4.7K) 71.0/31.7...
  • Page 42 [DSP-1 UNIT] [DSP-1 UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R3685 7030009591 S.RES ERA3YED 472V (4.7K) 37.7/37.2 C3053 4030019990 S.CER C1005 JB 1C 104K-T 65.5/23.9 R3686 7030009591 S.RES ERA3YED 472V (4.7K) 37.7/39.0 C3054 4030019990 S.CER C1005 JB 1C 104K-T 85.6/2.6 R3687 7030009591 S.RES ERA3YED 472V (4.7K) 48.3/39.2...
  • Page 43 [DSP-1 UNIT] [DSP-2 UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C3702 4030019560 S.CER GRM21BB31C106KE15L 50.2/37.3 IC8001 1180004180 S.REG ADP2323ACPZ-R7 <FE> 74.7/11.8 C3703 4030018580 S.CER C1608 CH 1H 821J-T 39.5/18.4 IC8003 1130012850 S.IC SN74LVC3G34DCUR 78.8/17.8 C3704 4030018580 S.CER C1608 CH 1H 821J-T 39.2/21.5 IC8201 1140015432 S.IC...
  • Page 44 [DSP-2 UNIT] [DSP-2 UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R8213 7030005240 S.RES ERJ2GEJ 473 X (47K) 25.6/18.5 R8325 7030004980 S.RES ERJ2GEJ 101 X (100) 67.7/36.5 R8214 7030005240 S.RES ERJ2GEJ 473 X (47K) 34.5/30.8 R8326 7030003200 S.RES ERJ3GEYJ 100 V (10) 61.1/35.3 R8215 7030007260 S.RES ERJ2GEJ 330 X (33)
  • Page 45 [DSP-2 UNIT] [DISPLAY UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION C8259 4030019990 S.CER C1005 JB 1C 104K-T 9.1/26.7 IC6001 1110005771 S.IC S-80942CNMC-G9CT2G 62.4/9.1 C8260 4030019990 S.CER C1005 JB 1C 104K-T 43.3/15.7 IC6002 1130007111 S.IC TC7W04FU(TE12LF) 89.9/37.1 C8261 4030019990 S.CER C1005 JB 1C 104K-T 38.1/15.6 IC6004 1140016600 S.IC...
  • Page 46 [DISPLAY UNIT] [DISPLAY UNIT] PARTS PARTS DESCRIPTION DESCRIPTION LOCATION LOCATION R6311 7030003640 S.RES ERJ3GEYJ 473 V (47K) 71.8/20.9 5030003450 LCD CMF2P2007-E <SKD> R6326 7030003560 S.RES ERJ3GEYJ 103 V (10K) 37.6/9.1 DS6301 5040002930 S.LED SML-512MW T86 23.2/39.2 R6327 7030003270 S.RES ERJ3GEYJ 390 V (39) 31.9/13.8 DS6302 5040002930 S.LED SML-512MW T86...
  • Page 47 [MIC UNIT] PARTS DESCRIPTION LOCATION C6901 4030006860 S.CER C1608 JB 1H 102K-T 8.5/8.6 J6901 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M) 10.0/5.0 J6902 6510022440 CON LTW-8MP-C NUTGASKET <LIA> Eqv.= This component is equivalent to the REF No. component listed above, and M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side) may be substituted on parts orders and repairs.
  • Page 48 SECTION 7. MECHANICAL PARTS [CHASSIS PARTS] [MAIN UNIT] ORDER ORDER DESCRIPTION QTY. DESCRIPTION QTY. J1001* 6510023092 20FLT-SM2-TB (LF) (SN) (M) W101** 8920000170 CAB-1017 W102** 8920000550 CAB-1058 [EXP-01] J1002* 6510027580 16FLT-SM2-TB (LF) (SN) (M) J1003* 6510027950 BM13B-SRSS-TBT (LF) (SN) 8920000550 CAB-1058 [AUS-01] J1004* 6510021722 30FLT-SM2-TB (LF) (SN) (M)

  • Page 49: Front Unit

    [DRIVER UNIT] [DISPLAY UNIT] ORDER ORDER DESCRIPTION QTY. DESCRIPTION QTY. MP6851* 8410002480 2429 PA HEATSINK J6001* 6510029490 10FLZ-SM2-TB (LF) (SN) J6002* 6510028030 28FLZ-SM2-GB-TB (LF) (SN) J6003* 6510027950 BM13B-SRSS-TBT (LF) (SN) J6005* 6510022621 10FMN-BMTTR-A-TBT (LF) (SN) [DSP-1 UNIT] 5030003450 CMF2P2007-E <SKD> ORDER DESCRIPTION QTY.
  • Page 50 [ACCESSORIES] [ACCESSORIES] ORDER ORDER DESCRIPTION QTY. DESCRIPTION QTY. 5210000840 ATC-30 MP15 8930081930 3311 B-MIC ANGLE [EXP-03] 8930081930 3311 B-MIC ANGLE [AUS-03] (Optional) HM-193 [EXP-01] 8930081930 3311 B-MIC ANGLE [USA-03] (Optional) HM-193 [AUS-01] 8930081930 3311 B-MIC ANGLE [UN-03] (Optional) HM-193 [USA-01] MP16 8810000660 PH M4 X14 SUS [EXP-03]...
  • Page 51 • For • For [EXP-02], [AUS-02], [USA-02], [UN-02] [EXP-03], [AUS-03], [USA-03], [UN-03] MP15 MP14 MP19 MP10 MP12 MP19 MP10 MP11 Separation kit MP10 MP12 MP11...
  • Page 52 MP7(CHASSIS)×4 (8810005771) MP17(CHASSIS) (8110009990) MP48(CHASSIS)×2 (8930083200) MP22(CHASSIS) (8930082010) MP6(CHASSIS)×4 (8810004301) MP46(CHASSIS) MP1005(MAIN) MP25(CHASSIS) (6950000040) (8510020190) (8930082040) MP1010(MAIN) (8930065741) MP1015(MAIN) (8930058840) MP4(CHASSIS) MP1006(MAIN) (8820000530) (8510020140) MP1003(MAIN) (8510020070) MP5(CHASSIS)×2 MP55(CHASSIS)×4 (8810008661) MP1004(MAIN) (8930084360) (8510020080) W107(CHASSIS) MP5(CHASSIS)×7 (8900019690) W101(CHASSIS) BOTTOM VIEW MP1009(MAIN) (8810008661) (8920000170) (8510020130) MAIN UNIT...
  • Page 53 The combination of top side and bottom side of this SECTION 8 BOARD LAYOUTS • DISPLAY UNIT B-7821B (TOP VIEW) S6303 S6302 S6322 DS6302 DS6301 DS6314 S6304 S6301 S6323 C6310 DS6320 DS6319 IC6014 DS6309 C6309 R6350 S6324 DS6324 DS6323 DS6310 S6325 S6305 S6306...
  • Page 54 The combination of top side and bottom side of this • DISPLAY UNIT B-7821B (BOTTOM VIEW) B7821B C6006 C6060 C6048 C6053 C6061 Q6002 CMSEL L6002 VLED C6033 Q6003 EP6009 C6059 C6054 J6002 EP6001 C6016 R6021 C6002 C6004 R6081 R6082 R6354 R6009 R6010 C6035...
  • Page 55 The combination of top side and bottom side of this • MAIN UNIT B-7818B (TOP VIEW) J1001 TO PA UNIT R1428 C1452 B7818B L1433 R1441 C1300 R1442 R1532 C1246 R1176 C1470 R1445 Q1111 R1533 Q1112 Q1409 J1001 R1429 R1440 C1469 L1418 L1410 L1455...
  • Page 56 The combination of top side and bottom side of this • MAIN UNIT B-7818B (BOTTOM VIEW) EP1006 C1002 C1009 C1880 EP1003 R1001 L1456 C1005 EP1004 EP1007 R1993 R1978 C1003 R1963 C1904 C1872 Q1814 C1414 L1817 Q1103 C1874 L1810 C1897 C1899 C1898 EP1804 C1006...
  • Page 57 The combination of top side and bottom side of this L4003 B-7827C C4030 R4011 C4023 • PA UNIT B-7827C R4019 R4020 Q4002 L4002 R4002 J4001 (TOP VIEW) C4035 R4033 J4009 J5002 R4026 L4020 J4009 C4026 C4037 C4038 R4069 R4068 R5109 J5005 R5108 C4044...
  • Page 58 The combination of top side and bottom side of this • PA UNIT B-7827C C4099 R4009 R4023 C4022 (BOTTOM VIEW) C4025 D5084 D5087 D5091 D5090 D5089 D5088 D5083 D5082 R4006 C5360 R4008 Q5019 R5002 C4040 EP4003 C4047 R5007 R5008 D5002 C4043 C5113 C5071...
  • Page 59 The combination of top side and bottom side of this • DSP-1 UNIT B-7819B (TOP VIEW) J3306 J3305 MP9 (IC clip) J3306 J3305 IC3011 R3100 R3101 R3102 C3666 R3662 R3686 R3699 C3727 C3728 C3729 J3007 C3014 R3018 R3032 L3603 R3666 R3685 C3061 C3705...
  • Page 60 The combination of top side and bottom side of this • DSP-1 UNIT B-7819B (BOTTOM VIEW) D3607 D3606 C3689 EP3012 R3647 R3044 R3692 C3639 C3688 R3724 C3020 C3011 R3725 R3726 C3041 C3009 IC3607 IC3615 R3727 C3690 R3078 C3048 IC3003 R3728 C3691 R3074 EP3007...
  • Page 61 SECTION 9 GENERAL WIRING ANT TUNE GPS EXMOD DC IN CFU-F8100 DSP2 W117 OPC-2139 W103 EP4004 J5005 EP4005 DSP1 W119 MAIN J1003 HM-192 RMK-6 CMSEL VLED MICG J6001 J6901 J6902 1:MIC DISPLAY 2:MIC SW1 3:AF OPC-2083B MICE MICE 4:MIC SW2 5:PTT J6003 6:GND...
  • Page 62 SECTION 10. BLOCK DIAGRAM 3rd IF 36kHz 2nd IF 455kHz 1st IF 64.455MHz fc=30MHz Q1810 Q1404-Q1407 D1405 D1406 D1409 Q1413 FI1402 D1414 FI1401 D1403 IC1403 Q1411 Q1412 Q1415 L1446 IC1402 D1812 D1813 Q1414 D1420 D1416 D1412 D1418 D1411 D1408 RXIF CERAMIC TX/RX XTAL...
  • Page 63 DSP-1 TO PA UNIT J5011 J3308 A/D converter D/A converter IC3608 IC3613 TO ACC D-SUB 9PIN IC3602,IC3603 IC3614 IC3003 TKEYS FOR ANT TUNE R3IF RX IF 36KHz RXIF BUFF BUFF Q3011 START TSTART CTRL TCON IC3601,IC3602 IC3601 IC3617 IC3614 IC3001 D3601,D3602 J3305 HIC3628...
  • Page 64 SECTION 11. VOLTAGE DIAGRAM • DISPLAY UNIT (1/2) IC6007 to LCD R6348 J6002 TX=0.5V Q6304 2.2k VOUT 2SD1802 RX=4.9V S-812C36AMC to MAIN UNIT J6003 R6346 CMSEL 3.6V VLED HVLED Sheet 2 EP6009 MMZ1608Y102BT BLED R6347 EP6001 MMZ1608Y102BT 13.4V LEDC2 EP6004 MMZ1608Y102BT MICG PTT_...
  • Page 65 • DISPLAY UNIT (2/2) S6308 1(QZ) SKRPACE010 S6309 10.0V 2(ABC) 3.6V SKRPACE010 S6310 3(DEF) CPU3V SKRPACE010 HVLED S6301 S6311 LEDC 4(GHI) Sheet 1 BLED SKRPACE010 SKRPACE010 S6302 S6312 LEDC2 EMGK 5(JKL) SKRPACE010 SKRPACE010 S6303 S6313 BACK LIGHT 6(MNO) ▲(VOL) SKRPACE010 SKRPACE010 S6304 S6314...
  • Page 66 • MAIN UNIT (1/6) FRONT TUNER CONTROL Sheet 6 Sheet 3 VBUSK TCON TSTART J1004 CP05S TSTART BEEP BEEP TCON CP1930 VBUSK R3IF R3IF USB_GND GPRXD GPRXD GPTXD EXRXD EXRXD EXTXD EALC 3DST 3.3V 3DST REFV REFV Sheet 4 3.3V 3.3V to DSP1 3PCK...
  • Page 67 C1285 • MAIN UNIT (2/6) MAIN To MAIN UNIT (3/6) C1147 R1964 C1280 L1126 L1141 D1120 IC1104 D1112 C1244 D1131 D1133 BST_2 MDT_2 EXRE_2 1SV308 4.7U 4.7U 1SV308 1SV308 1SV308 MC_2 BST_2 R1197 R1161 PROF_ EXRE_2 R1198 EXRE MC_2 R1199 L1118 MDT_2 R1200...
  • Page 68 • MAIN UNIT (3/6) L1811 TX=7.9V RX=7.9V R1438 IMD3A L1419 L1422 C1451 C1457 Q1814 C1445 C1471 Q1410 0.01 TX=4.5V R1434 2SC3357 TX=6.8V RX=0V Sheet 1 RX=0V C1409 R1422 C1464 R1564 L1432 0.0047 DRVC C1525 R3IF DSPO1 L1416 C1465 VCT4 IC1401 0.1U 0.0047 VCT5...
  • Page 69 • MAIN UNIT (4/6) 4.9V EP1602 MMZ1608Y102BT IC1606 C1667 C1668 256MHz C1666 C1620 C1625 C1631 C1636 L1614 L1615 L1618 C1657 256MHz 0.001 UPC2709TB C1640 C1649 C1643 0.5P C1907 IC1820 C1908 MARKER_OUT 0.5P TC7S08F Sheet 2 IC1602 R1605 L1602 L1604 C1614 64MHz 0.1U 0.12U...
  • Page 70 • MAIN UNIT (5/6) Sheet 1 R1701 1CNO_5 1CNO R1702 EXRE R1705 1DST_5 1DST LOF0 LOF0 LOF1 IC1702 LOF1 SN74LVC3G34DCUR R1712 R1713 Sheet 4 3.3V 3PCK 3PCK 256M IC1701 TC7WH04FU L1703 EXRE_5 Sheet 2 MMZ1608Y102BT EP1707 IC1704 UPD120N18TA UMD3N UMD3N Q1701 Q1702 EP1704...
  • Page 71 • MAIN UNIT (6/6) PA(non switvhed 13V) IC1801 S-812C50AUA R1815 C1836 C1841 3DST 3DST IC1805 1DST PA(switched 13V) 1DST L1802 CP05S CP1812 IC1810 HF50ACC322513 CP1813 SW ON=4.8V CP1824 EXRE R2024 CP08S SW OFF=0V CF20 R2025 R2026 IC1804 R1EX24512ASAS0A CD4028BNSR CP05S R2022 CP1826 VLED...
  • Page 72 • PA UNIT (1/2) DRIVER UNIT L4010 R4046 C6851 EXC-ELDR25C 0.01 R4038 R6852 R4039 Q4006 Q6851 R4040 SD1487 J4004 PD55015 J4005 R4022 C4044 DRVI DRVO DRVI DRVO C4062 0.0068 R4011 R4021 C4030 Q4003 PD55003 R4034 C4099 L4005 EXC-ELDR25C L4009 L4012 L4014 L4015 R4002...
  • Page 73 • PA UNIT (2/2) D5088 D5089 D5090 D5091 1SS403 1SS403 1SS403 1SS403 D5086 D5087 D5084 D5085 1SS403 1SS403 1SS403 1SS403 J5002 L5011 L5012 L5013 MAIN LR-571 LR-571 LR-570 L5001 L5002 RL5011 FTR-B4CA012Z L5112 Q5001 FTR-B4CA012Z RL5001 DTC114EU 0.33U 0.27U C5204 C5209 C5213 FTR-B4CA012Z...
  • Page 74 • DSP-1 UNIT (1/2) TCON(TXD3) D3606 to MAIN J3305 J1004 EXRE EXRXD IC3012 DA221 TUNER L3607 Q3011 GPRXD 100U DTC114EU BEEP J3001 START UDRES EP3012 UPWS MMZ1608Y102BT TSTART TSTART R3026 R3737 R3736 BEEP TCON TCON MSEL1 L3608 VBUSK VBUSK HF50ACC322513 R3IF USB_GND D3607...
  • Page 75 • DSP-1 UNIT (2/2) Sheet 1 3.3V 3.3V 3.3V -12V -12V -12V IC3617 IC3602 IC3601 to DSP-2 AD8599 ADA4075 ADA4075 J8203 J3303 CTX1 IC3610 CTX2 CRX1 CLKC FS/SUSPEND/OE/SHUTDOWN CRX2 C3669 R3625 XTALIN CLKA IC3608 XTALOUT CLKB C3620 680P R3618 VREFL VREFR 2.7k R3630...
  • Page 76 • DSP-2 UNIT (1/3) IC8216 DSP2AFO RTOP TC7W53FU 1.5k U1TX U1TX To SHT003 RBOT R8004 R8005 U1RX U1RX To SHT003 820P IC8217 R8007 R8009 C8005 DSP2AFI U1RT U1RT To SHT003 MPZ2012S331A 0.022 U1CT F8002 U1CT To SHT003 EP8001 L8001 7E08L-100M C8008 To SHT002 C8007...
  • Page 77 • DSP-2 UNIT (2/3) IC8203 BD12KA5FP VBUS VBUS UPWS UPWS 1.2V UDRES UDRES EXTXD EXTXD EXRXD EXRXD IC8204 IC8205 1 OUT DSP2AFO DSP2AFO 2 VDD DSP2AFI DSP2AFI 3 VSS MODPTT MODPTT TC7S08FU S-80830CNMC CP8215 EP8202 3.3V MPZ1608S221A 3.3V CP06S for power-on sequence DRFS DRFS Q8011...
  • Page 78 • DSP-2 UNIT (3/3) To SHT 002 R8326 CP8235 R8327 IC8214 IC8215 CF20OPEN 3.3V 3.3V VBUS To SHT 002 VOUT VOUT VBUS R8325 CTRL CTRL R8328 NJU7772F33 NJU7772F33 UPWS To SHT 002 EP8212 UPWS CP8234 MMZ1608Y102BT CF20 UDRES To SHT 002 UDRES U1TX To SHT 001...
  • Page 79 Highway 17 Delta, B.C., V4K 5B8, Canada : http://www.icomspain.com Phone : +1 (604) 952-4266 Fax : +1 (604) 952-0090 E-mail : icom@icomspain.com : http://www.icomcanada.com E-mail : info@icomcanada.com Blacksole House, Altira Park, Herne Bay, Kent CT6 6GZ, UK Phone : +44 (0) 1227 741741...
  • Page 80 S-15005XZ-C1 1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2013 Icom Inc.
