Dialogic® Vision™ CX Video Gateway Administration Manual

Viewing trunk and circuit status information

To view trunk and circuit status information, follow these steps:
Step Action
1 Access the Vision™ Console, as described in Accessing the Vision Console on page 33.
2 Click Trunks in the Monitoring menu.
The Trunks page appears. It displays an illustration of trunk and circuit states, which shows:
•
The total number of circuits.
•
Whether a circuit is idle, busy, out of service, or blocked.
•
Whether a trunk is in sync or in an alarm state. If a trunk is in an alarm state, the Trunks
page shows the alarm.
Note: Trunk states unavailable, unequipped, congested, and trunk-down show up as a tool tip
on this page.
Dialogic
Managing the CX Video Gateway
83
