Dialogic® Vision™ CX Video Gateway Administration Manual

Trunks

The Trunks page configures trunk settings and circuit groups. Access this page by
clicking Trunks on the Configuration menu.
Group Associated
implementations
Trunk All
configuration
PSTN routes All
Board #0 All
trunks
Board #1 Implementations where the
trunks gateway has two media
boards
Board #2 Implementations where the
trunks gateway has three media
boards
Values for the PSTN routes group
Use a circuit code identifier (CCI) to identify a PSTN route. A CCI is an integer
ranging from 1 to the highest circuit (CCI max). For example, if the routes contain
four E1 trunks (each containing 30 circuits), circuits are numbered from 1 to 120.
The value of CCI max is 120.
Dialogic
Parameter Description
Frame type Indicates frame type of T1 or E1.
CRC signal Indicates whether the media resource
checking provides CRC signal checking.
Line Type of cable connecting the media
impedance resource to the T1 or E1 network.
Trunk Framing format.
framing
Line code Ones density maintenance method
used on the trunk line to maintain a
clear channel transmission.
Clock source Media board's clock source.
•
Network: source is from the
PSTN.
•
Internal: source is from the
internal oscillator.
Route 1 - Defines the route circuits reserved for
Route n outgoing PSTN calls, and specifies
how the circuits are selected.
For a description of the valid values,
see Values for the PSTN routes group
on page 45.
Click Add to reserve another route
circuit for outgoing PSTN calls.
Trunk 1 - Indicates whether the specified trunk
Trunkn on Board 0 is enabled or disabled, and
specifies the PSTN route associated
with the trunk.
Trunk 1 - Indicates whether the specified trunk
Trunkn on Board 1 is enabled or disabled, and
specifies the PSTN route associated
with the trunk.
Trunk 1 - Indicates whether the specified trunk
Trunkn on Board 2 is enabled or disabled, and
specifies the PSTN route associated
with the trunk.
Vision™ Console parameters
45
