Dialogic® Vision™ CX Video Gateway Administration Manual
Basic ISUP video model
In the basic ISUP video model, the gateway:
Provides ISUP signaling with 3G-324M.
•
Provides SIP signaling.
•
Provides the option to transcode between AMR and G.711.
•
Supports the Call Control Extensible Markup Language (CCXML) for call
•
control.
The basic ISUP video model requires a mobile video device that supports 3G-324M.
The following illustration shows the basic ISUP video model:
ISUP
SS7 access
network
E1
(3G-324M)
Dialogic
SIP
CX Video
Gateway
RTP AMR (audio)
RTP H.263 (video)
Overview of the CX Video Gateway
IP
network
17
