Dialogic® Vision™ CX Video Gateway Administration Manual
Step
Action
4
To add a CCXML application as a custom application, click New at the bottom of the Custom
section, and enter the following information:
Field
Number
range
Initial URI
Dialog
servers
Outbound
routes
For information about creating call routes for custom CCXML applications, see Fine tuning
gateway routing on page 126.
Dialogic
Description
Number range associated with the CCXML application specified by the
Initial URI value. The number range can be a combination of numbers,
alphabetic characters, and wildcards.
The gateway checks if the dialed number of an incoming call matches this.
If it finds a match, the corresponding CCXML application is executed.
If the dialed number matches the number range of multiple applications,
the call is matched to the most specific number range.
For more information, see CCXML application definition pattern matching
syntax on page 91.
Initial URI to use for an incoming all, based on the number range of the
dialed number.
List of dialog servers for the application. Separate each dialog server with
a comma.
List of outbound routes for the calls that the CCXML application creates.
Separate each route with a comma.
PSTN routes
For a PSTN route, the syntax is:
route-Route_Number[Priority]
where:
•
Route_Number identifies a PSTN route, as defined in the telecom
conf file.
•
Priority specifies the priority level for load balancing over the
telecom routes.
If Route_Number is set to 0, the route is chosen automatically according
to the associated incoming call.
SIP routes
For a SIP route, the syntax is:
IP_Address:Port[Priority]
where:
•
IP_Address:Port is the IP address and port of a SIP route.
•
Priority the priority level for load balancing over SIP routes.
For both PSTN and SIP routes, Priority is optional, and its value is
relative from 0 (default) to any required level. The highest priority is
expressed by the lowest value (typically 0). Load balancing is performed
between routes with the same priority and starts by routes defined with
the highest priority.
Note: If you have outbound PSTN routes defined in the CCXML
application, the CX Video Gateway processes those routes before it
processes the routes defined here.
Managing the CX Video Gateway
89
