Fine tuning the CX Video Gateway configurationDialogic® Vision™ CX Video Gateway Administration Manual
Specifying T1 trunk settings
Specify the following settings in the media board configuration file for a media board
that uses T1 trunks:
Keyword
NetworkInterface.T1E1[0..3].LineCode
NetworkInterface.T1E1[0..3].FrameType
The following example shows the default settings in the media board files for the
ISDN audio and ISDN video models. Replace the bold default values, if necessary.
NetworkInterface.T1E1[0..7].Type
NetworkInterface.T1E1[0..7].Impedance
NetworkInterface.T1E1[0..7].LineCode
NetworkInterface.T1E1[0..7].FrameType
NetworkInterface.T1E1[0..7].CRCMFMode
NetworkInterface.T1E1[0..7].SignalingType
NetworkInterface.T1E1[0..7].D_Channel
MaxChannels = 512
114
Setting
For each trunk on the media board, optionally specify the
ones density maintenance method used on the trunk line to
maintain a clear channel transmission.
Valid values:
B8ZS (Default)
AMI
AMI_ZCS
AMI_BELL
AMI_DDS
AMI_GTE
For each trunk on the media board, specify the T1 trunk
framing format for the current trunk.
Valid values:
D4
ESF (Default)
= T1
= DSX1
= B8ZS
= ESF
= C44ON
= PRI
= ISDN
