Vision™ Console parameters

Trunks page

The Trunks page displays a trunk monitoring chart. Access this page by clicking
Trunks on the Monitoring menu.
Field Description
Circuits Total number of configured circuits.
Information about circuit states.
Valid values:
•
Idle: Circuit not used
Circuit
•
Busy
states
•
Out of service
•
Blocked
•
Unknown
Information about trunk (line) states.
Valid values:
•
In sync
Trunk
•
Yellow alarm
states
•
Blue alarm
•
Red alarm
(ISUP models) Number of circuits reserved for signaling (raw circuits). The Vision™ Console
Signaling displays this information when you hover over an unknown circuit in the trunk monitoring
chart.
Information about blocked circuits, if any. The Vision™ Console displays this information
when you hover over a blocked circuit in the trunk monitoring chart.
Valid values:
•
local-maintenance: Circuit is locally blocked for maintenance.
Blocked
•
remote-maintenance: Circuit is remotely blocked for maintenance.
•
local-hardware: Hardware is locally blocked.
•
remote-hardware: Hardware is remotely blocked.

CCXML statistics

The CCXML statistics page displays a bar chart that represents the following
statistics:
Number of active CCXML sessions, connections, and dialogs.
•
Maximum number of CCXML sessions, connections, and dialogs.
•
Access this page by clicking CCXML statistics on the Monitoring menu.
58
Dialogic® Vision™ CX Video Gateway Administration Manual
