Dialogic® Vision™ CX Video Gateway Administration Manual
Group Associated
implementations
All ISUP
ISUP circuits
definition
Implementations
where transport is
MTP
MTP links
Implementations with
redundant servers
Remote MTP links
Dialogic
Parameter Description
Add new DPC Enter the destination point code for
another circuit, and click Add New
DPC to add another destination point
code to the list.
Index Circuit group index.
Start circuit Starting number of the circuit group
that the signaling server or signaling
server pair can handle.
Start CIC Starting CIC of the circuit group that
the signaling server or signaling
server pair can handle.
Number of Number of circuits in the circuit
circuits group.
DPC Destination point code associated
with the circuit group.
Unused circuits A space-separated list of circuits
within the range of this circuit group
that are not controlled by ISUP.
Edit Removes the current circuit
definition.
Trunk T1 or E1 trunk used for signaling.
The values in this field vary,
depending on the number of boards
and the trunk configuration.
Status If checked, indicates that the MTP
link is enabled.
DPC Destination point code associated
with each route.
SLC Signaling link code.
Signaling Timeslot on the signaling trunks to
timeslot be reserved for signaling.
For E1 line types, the value is usually
16.
Speed Speed of the signaling link in Kbps.
Index Index of the link definition.
Port Number Remote TX Board port number
(corresponds to the MTP link index
configured on the remote server).
SLC Signaling link code of the remote
link.
DPC Destination point code of the remote
link.
Edit Removes the current remote link
definition.
Vision™ Console parameters
