Dialogic® Vision™ CX Video Gateway Administration ManualFine tuning the CX Video Gateway configuration
Parameter
media_board_num
trunk_vendor_id
trunk_type
isdn_equipment
-r
channel_reserved
Dialogic
Description
Logical board index of the media board containing the trunk, referring to a
board previously declared with the Media_board keyword.
Valid values: 1 - 8.
For information about the Media_board keyword, see the Dialogic® Vision™
Call Server Administration Manual.
Vendor identifier of the trunk.
Valid values: 0 - 15
(Optional) Type of trunk.
Valid values:
•
E1 (30 media channels)
•
T1 (23 media channels)
•
E1RAW (31 media channels)
•
T1RAW (24 media channels)
Default: E1.
(ISDN models only) Type of equipment connected to the trunk.
Valid values:
•
NT = Network equipment
•
TE = Terminal equipment
Default: TE
(ISUP models only) Reserved channel.
Use the -r switch to declare a voice channel as unusable for audio purposes.
The channel-reserved value corresponds to the voice timeslot to reserve.
Channels are numbered from 0 to (maximum number of voice timeslots) - 1.
Valid values:
•
T1 trunks: 0 - 23
•
E1 trunks: 0 - 30
