Settings for ISUP models that use native ISUP signaling

Use the ISUP_board keyword to specify information for ISUP models that use native
ISUP signaling. Replace the parameters shown in the table with the appropriate
values.
ISUP_board 1 1 SS7_node_pc SS7_switch_type
Parameter Description
SS7_node_pc Point code of the gateway in the ISUP network.
This value should be the same as the value for SS7_node_pc in the Overall MTP
parameters section of the MTP3cp1.cfg file and the General configuration section
of the ISUPcp1.cfg file.
SS7_switch_type SS7 protocol variant. Declare the same SS7 protocol variant in the isupcp1.cfg
file and in the ss7load.bat or ss7load file.
Valid values are:
122
•
ANS88 = ANSI 88 (ref. T1.123 – 1988)
•
ANS92 = ANSI 92 (ref. T1.113 – 1992)
•
ANS95 = ANSI 95 (ref. T1.113 – 1995)
•
ETSIV2 = ETSI v2 (ETS 300 356)
•
ETSIV3 = ETSI v3 (ETS 300 356-1 – 1998)
•
ITU97 = ITU-T 1997
•
ITUBLUE = ITU-T Blue Book
•
ITUWHITE = ITU-T White Book
•
JTTC = JTTC (Japan TTC)
•
JNTT = JNTT (Japan NTT)
•
Q767= ITU-T Q.767
