Settings for the ISUP models with Vision™ Signaling Servers
Use the VS_isup_server keyword to specify information for ISUP models with
Signaling Servers. Replace the parameters shown in the table with the appropriate
values.
VS_isup_server 1 1 ISUP_start_circuit SS7_node_pc SS7_switch_type
signaling_and_bearer_type
Parameter
ISUP_start_circuit
SS7_node_pc
SS7_switch_type
signaling_and_bearer_type
The following telecom.conf file example shows how to configure two Vision™
Signaling Servers. In this example, Signaling Server 1 services circuit 121 and
higher, and uses point code 100. Signaling Server 2 services circuits 1 - 120, and
uses point code 200. Both signaling servers support the ETSIV2 ISUP protocol
variant.
# Signaling board
VS_isup_server 1 1 121 100 ETSIV2 ISUP
VS_isup_server 2 2 1 200 ETSIV2 ISUP
The following telecom.conf file example shows how to configure a Vision™ Signaling
Server to use ITU-T BICC over IP.
# Signaling board
VS_isup_server 1 1 1 204 ITUBICC BICC+IP
Dialogic
Description
Circuit identifier of the first circuit that the signaling server will
handle.
Point code assigned to the signaling server in the ISUP network.
SS7 protocol variant that the signaling server uses. Valid values are:
•
ANS88 = ANSI 88 (ref. T1.123 – 1988)
•
ANS92 = ANSI 92 (ref. T1.113 – 1992)
•
ANS95 = ANSI 95 (ref. T1.113 – 1995)
•
ANSIBICC = ANSI BICC (T1.BICC.1-2000 to T1.BICC.7-2000)
•
ETSIV2 = ETSI v2 (ETS 300 356)
•
ETSIV3 = ETSI v3 (ETS 300 356-1 – 1998)
•
ITU97 = ITU-T 1997
•
ITUBICC = ITU-T BICC (Q.1901, Q.1902-6)
•
ITUBLUE = ITU-T Blue Book
•
ITUWHITE = ITU-T White Book
•
JTTC = JTTC (Japan TTC)
•
JNTT = JNTT (Japan NTT)
•
Q767= ITU-T Q.767
Signaling and bearer type that the signaling server uses. Valid values
are:
•
ISUP = ISUP
•
BICC+IP = BICC with IP bearer channels
Default: ISUP.
