Specifying your audio output settings

The audio output page lets you adjust various settings for your audio output from
your MXO2 system. For example, you can adjust the volume of your analog
audio output before or while playing back clips, and choose to output audio
through your system's sound card instead of your MXO2 system.
° To specify your audio output settings:
Choose Sequence > Sequence Settings and click the Playback
1
Settings
Click the Audio Output tab.
2
Under Analog Audio Volume , drag the sliders to adjust the volume of your
3
analog audio output. By default, the sliders are locked so that they move
together. To move each slider independently, click the lock button (
disable it.
Under SDI Audio Output Format , select the bit depth you want for your
4
embedded SDI audio output ( 20-bit or 24-bit ). This setting is not available
on MXO2 Mini.
Under HDMI Audio Output , select Output only two audio channels if
5
you want to output two audio channels from the MXO2 HDMI output,
instead of eight channels. This option is especially useful for HDMI
monitors that don't accept more than two audio channels.
button.
Defining your sequence settings
65
) to
