Supported capture formats for Matrox MAX
H.264 Capture
The following table lists the supported capture formats when using the Matrox
MAX H.264 Capture application to capture clips to Matrox .264 and .mp4 files,
based on your selected video input format (supported only on Matrox MXO2
products with MAX technology or a Matrox CompressHD card). For a list of the
video input formats supported on the various MXO2 inputs for capturing clips,
see "Supported input formats"
Video input format
NTSC
PAL
720p @ 50 fps
720p @ 59.94 fps
1080i @ 25 fps
1080i @29.97 fps
1080PsF @ 23.98 fps
1080PsF @ 25 fps
1080PsF @ 29.97 fps
1080p @ 23.98 fps
1080p @ 24 fps
1080p @ 25 fps
1080p @ 29.97 fps
1080p @ 30 fps
1
Any_ respresents a custom frame size that you can enter for your Matrox .mp4 file as explained in
"Specifying your capture format settings"
Appendix C, Matrox MXO2 Supported Input and Capture Formats
on page 244.
Matrox 264 (Blu-ray)
720p @ 59.94 fps or 1080i @29.97 fps
720p @ 50 fps or 1080i @ 25 fps
720p @ 50 fps or 1080i @ 25 fps
720p @ 59.94 fps or 1080i @29.97 fps
720p @ 50 fps or 1080i @ 25 fps
720p @ 59.94 fps or 1080i @29.97 fps
720p @ 23.98 fps or 1080p @ 23.98 fps
720p @ 50 fps
—
720p @ 23.98 fps or 1080p @ 23.98 fps
720p @ 24 fps or 1080p @ 24 fps
720p @ 50 fps
—
—
on page 212.
Captured file format
720p @ 59.94 fps, Any_
or Any_p @ 29.97 fps
720p @ 50 fps, Any_p @ 12.5 fps, or
Any_p @ 25 fps
720p @ 50 fps, Any_p @ 12.5 fps, or
Any_p @ 25 fps
720p @ 59.94 fps, Any_p @ 14.98 fps,
or Any_p @ 29.97 fps
720p @ 50 fps, Any_p @ 12.5 fps, or
Any_p @ 25 fps
720p @ 59.94 fps, Any_p @ 14.98 fps,
or Any_p @ 29.97 fps
Any_p @ 11.99 fps or
Any_p @ 23.98 fps
720p @ 50 fps, Any_p @ 12.5 fps, or
Any_p @ 25 fps
Any_p @ 14.98 fps or
Any_p @ 29.97 fps
Any_p @ 11.99 fps or
Any_p @ 23.98 fps
Any_p @ 12 fps or
Any_p @ 24 fps
720p @ 50 fps, Any_p @ 12.5 fps, or
Any_p @ 25 fps
Any_p @ 14.98 fps or
Any_p @ 29.97 fps
Any_p @ 15 fps or
Any_p @ 30 fps
Matrox MP4
1
p @ 14.98 fps,
