Connecting MXO2 LE to your computer

Connect MXO2 LE to your desktop computer or laptop using the Matrox PCIe
cable. For MXO2 LE to be detected on your desktop computer, power must be
supplied to MXO2 LE (see
connected to your computer before starting up your system.
¡ Important Do not disconnect the Matrox PCIe cable from the adapter, or
MXO2 LE, when your computer is running. Shut down your laptop before
removing the Matrox PCIe host Expresscard/34 adapter from your laptop's
Expresscard/34 slot.
A
Chapter 5, Connecting External Devices to Matrox MXO2 LE
"Powering MXO2 LE"
²Caution Ensure proper orientation
PCIe cable
Matrox PCIe
host adapter
A
on page 30), and it must be
when connecting the PCIe cable to avoid
damaging the cable or host connector.
Matrox PCIe host
ExpressCard/34
adapter
OR
To your laptop's ExpressCard/34
slot (see "Installing and removing
your PCIe host ExpressCard/34
adapter (for laptops)"
MXO2 LE
(side view)
on page 7).
