Chapter 5

Fader Assign

FADER ASSIGN opens a matrix that allows you to assign any of the 8 Analog and/or 8 Digital inputs to any
or all of the 4 faders. You can assign any of the inputs to either the touch or hardware faders.
Hint: When assigning inputs to touch faders, you should not assign any input that you will be "riding" the levels
on, use the front hardware faders for those inputs.
Figure 11 Hardware faders Screen

Preset

You can preset up to five settings. These are automatically saved as you toggle through to the next pre-
set.

Analog/Digital Toggle

Toggles between the analog and digital inputs. You can assign any combination of digital and/or analog
inputs to the faders.

Clear All

Clears all inputs on the screen.
