Deva 5.8 and Deva 16 Owner's Manual
Chapter A
Appendix
There are some features in the Deva designed to help troubleshoot with the Zaxcom staff. These items
have been placed in areas of the Deva that are not usually accessed. This section of the manual covers
those items.

Diagnostic Menu

The Deva 5.8, contain a diagnostic mode which allows you to upgrade the firmware, and perform some
basic diagnostic routines.

Getting to the 1967 Menu

To get to the diagnostic menu perform the following steps:
1. Go to the Main Menu.
2. Press 1967 on the numeric keypad
The Deva goes into the diagnostic mode.
Important: If you enter the 1967 mode and want to exit, you can either power down the Deva or press the menu key.

Commands Available in 1967 Menu

All commands in the 1967 menu are proceeded by pressing the F5 function button on the Deva.
Key Combination Description
F5, then 1 Restart the Deva.
This can help some FireWire drives mount properly.
F5, then 2 Copy currently running program to FireWire or internal DVD disc.
This is called DevaProgFile.bin
F5, then 3 Copy currently running program to internal hard drive.
This allows you to startup from the hard drive. This is useful for using
multiple versions of firmware on your Deva.
F5, then 4 Reserved.
Not currently used.
F5, then 5 Prints debug information and puts a boot record on the internal disk for PC
access. Zaxcom use only.
F5, then 6 Copy DevaProgFile.bin from UDF formatted disk to memory.
Used when updating the firmware.
F5, then 7 Copy DevaProgFile.bin from non-UDF formatted disk to memory.
Used when updating the firmware.
F5, then 8 Prints debug information and prevents the Deva from mounting UDF discs.
F5, then 9 Burns the currently running program into ROM.
85
