Deva 5.8 and Deva 16 Owner's Manual
Note: Only meters displayed in the horizontal orientation display labels on the home screen due to space restrictions.

Changing the Meter Orientation from the Home Screen

A shortcut is available on the home screen allowing you to toggle the meter orientations quickly. Next to
the status mode is the view ('V') button. Pressing the view button toggles through the meter orientations.
Figure 34

Meter Color Schemes

The Bright and Black & White settings were designed for using the Deva in full sunlight. Both allow you to
see and use the Deva screen when viewing conditions are less than ideal.

Headphone Monitoring

One of the strengths of the Deva is the flexibility in routing, which is evident in the input, output, and
recording options. This flexibility is extended to the headphone monitoring area as well. Many common
headphone monitoring options come preset from Zaxcom. You can add up to 12 custom presets in
addition to the factory presets. You can also simply build a headphone monitoring configuration on-the-fly
without saving it, as well as temporarily monitor a single channel. The headphone audio you are listening to
what is being placed onto the hard drive. Check-Sum Error Correction ensures that what is being sent to
the internal hard drive is being recorded there.
Main Menu > Headphone Mix
Headphone Mix Menu
There are two shortcuts to getting to the Headphone Mix menu:
o Press the F6 key on the Deva,
o Press headphone display area on the home screen.
Both of these bring you immediately to the Headphone Mix menu, as long as fader number 8 is not assigned
to a track.
33
View Button Highlighted
Chapter 3
