Deva 5.8 and Deva 16 Owner's Manual

Adjusting the Trim

o Range: -20 dB to +30 dB

There are two ways to adjust the input trim on channels. If you have multiple inputs, the Analog Trim

Screen allows you adjust all of them from a single screen. However, if you are making individual adjustments

to channels the trim can be adjusted using the on-screen fader in the Input Channel menu (shown in

Figure 7).

Main Menu > Input Control > Adjust Trim

Figure 12

Press the Adjust Trim button.

The Analog Trim menu appears.

Press the meter for the channel you want to adjust.

When a channel is activated, Trim changes from black to Blue.

Either Less gain or More gain to adjust a channel.

Repeat steps 1 through 3 for each channel.

All Trim settings can be reset to 0 dB by pressing the Clear Trim button. A dialog appears after pressing the

Clear Trim button requesting confirmation that you want to clear all the trim settings.

Note: If all channels are going to be set at the same level, you can save time by changing them at the same time. Press the

Select All button, then any change made to the levels are applied to all channels at the same time.

Pressing either the STOP button in the upper right corner of the screen or using the Menu key on the

keypad exits the Adjust Analog Trim screen and brings you back to the Analog Input Control screen.

Analog Input Trim Menu

Chapter 2
