Chapter 4
AES Digital Input
The Deva uses a DB-15 connector for the AES digital input connnector.
Pin
1
2
3
4
5
6
7
8
AES Digital Output
The Deva uses a DB-15 connector for the AES digital outputs connnector.
Pin
1
2
3
4
5
6
7
8
Signal Description
Pin
CH 3, CH 4 +
9
CH 1, CH 2 +
10
No Connect
11
CH 7, CH 8 +
12
CH 5, CH 6 +
13
Ground
14
Ground
15
No Connect
Signal Description
Pin
CH 3, CH 4 +
9
CH 1, CH 2 +
10
No Connect
11
CH 7, CH 8 +
12
CH 5, CH 6 +
13
Ground
14
Ground
15
No Connect
Deva 5.8 and Deva 16 Owner's Manual
Signal Description
Ground
Ground
CH 3, CH 4 -
CH 1, CH 2 -
No Connect
CH 7, CH 8 +
CH 5, CH 6 +
Signal Description
Ground
Ground
CH 3, CH 4 -
CH 1, CH 2 -
No Connect
CH 7, CH 8 +
CH 5, CH 6 +
44
