Chapter 5

Serial Remote Roll

Enables the control of the Deva using the Serial port.

Serial Port Mode

Used in conjunction with the Serial Remote Roll, it determines the serial port protocol. The serial port can
either be configured as a standard RS-232 or Standard RS-422 port.

Command Monitor

Similar to Microsoft Windows DOS Prompt, or the UNIX terminal, it provides a command line to the
Deva. At this time, the Command Monitor has not been implemented and should not be used.

Master Output Mode

When the Deva MIX-12 is used, the Master Output Mode selects if the playback switch of the output bus-
ses is enabled or disabled.

Slate Source

The Slate Source toggles between the Deva internal mic and camera input as the source for slate.

Headphone Options

Opens a new window providing additional options for the headphones when monitoring.
Figure 16 Headphone Option Screen

Headphone Alarm Tone

Toggles On / Off any audible alarms.

Mute Unrecorded Tracks

When enabled, all tracks not being recorded are muted. This enables you to have multiple inputs into the
Deva still configured, but monitor only those inputs that are currently being recorded.
