Deva 5.8 and Deva 16 Owner's Manual

MIX-12

When a Deva MIX-12 is used with the Deva, a new MIX-12 button appears in the Deva Setup. The MIX-12
screen sets the following options.
o Mix-12 support
o Meter Brightness
o Tone Button Assign

Mix-12 Support

When a Mix-12 is connected to the Deva, you must toggle this button to the On position.
Note: After turning on Mix-12 support, you need to toggle the power on the Deva.

Meter Brightness

This sets the LED brightness on the MIX-12 console. The brightness can be set from 1 (dim) to 8 (bright-
est).

Tone Button Assign

Sets the action of the tone button on the Mix-12 console. The options are:
o Escape
Assigns the Tone button to goes back one screen on the Deva.
o Play
Assigns the Tone button to Play
o Unassigned
Disables the Tone Button
o Tone
Leaves the Tone Button assigned to the Tone function
o Home
Assigns the Tone button to go to the Home Screen.
67
Chapter 5
