Chapter 5

Mirror Mode

Enables the 'Mirroring' process which writes the audio to the selected drive.

Important: You must set the mirroring parameters before you turn on mirroring. Do not change folders while

mirroring is on. Doing so can cause the mirroring process to skip files or cause the Deva to stop responding.

You must turn off mirroring to change any of the parameters. When mirroring is ON, all the other buttons

are disabled until the mirroring process has completed.

Selects which folder you want to mirror.

Allows you to select the first segment to mirror. This setting is automatically updated when a disc is

inserted. If the Deva sees segment 5 is already on the disc the StartSeg is set to 6.

Hint:

A quick method to ensure your disc readable, is to eject and re-insert your mirrored disc after you are fin-

ished mirroring. Then check that the Deva recognizes the format and the Start segment is set to 1 past the

last recorded segment.

Allows you to select the last segment to mirror. In most cases the End Seg can be left at 999.

Select the tracks you wish to mirror.

This is the main playback screen. It is used to select Cues for playback.

Figure 35 Cue Mode Screen
