Chapter 1
2.
Headphone Output
1/4-in. Stereo Jack, optimal 100 Ω impedance.
Note: Lower headphone impedances result in louder headphone output levels.
3.
Analog Outputs 1- 6
25-pin connector outputs 6 channels of line level audio. You can select the channels assigned to these
outputs from the Deva menu.
4.
Camera Connector (Deva 5.8 only)
This is a standard 10-pin Hirose ENG type camera connector. It outputs Channels 5 and 6 to the camera and
returns the monitor feed from the camera.
Note: The two return monitor feeds are summed to mono.
5.
Battery Ejection Pin
This pin ejects the NP-1 battery from the battery compartment.
6.
Analog 9-12 Input Connector (Deva 16 only)
This 10-pin Hirose ENG connector is for the included cable, allowing you to use analog channels 9
through 12.
Deva 5.8 and Deva 16 Owner's Manual
8
