Chapter 2

Main Menu > Input Control > Input Channel

Figure 7

Switching Between Microphone and Line Input

The Mic/Line button on the Input Control menu allows you to toggle the analog inputs between the

microphone and line input.

Main Menu > Input Control

Figure 8

To toggle between the settings, perform the following:

Press the Mic/Line button on the screen.

The LED on the Mic/Line button flashes green indicating it is active.

Press the channel button on the screen for channel you want change.

The channel button displays the current mic/line setting

You can continue toggling the Mic/Line option to each channel as required without pressing the Mic/Line

Level button each time, simply press the channel you want power applied to while the LED flashes on the

Mic/Line Level button.

If you press the Mic/Line button without pressing the Mic/Line button, you open the Input Channel screen.

Single Channel Analog Input Screen

Mic/Line button
