Deva 5.8 and Deva 16 Owner's Manual
Main Menu > Headphone Mix > Get Factory Presets
Figure 36

Building Your Own Headphone Mix (Working Preset)

On the Headphone Mix menu, all tracks marked for recording are displayed in blue. All other tracks have a
red slash through them. This is shown in the following figure:
To build your own headphone mix, from the Headphone Mix menu perform the following:
1. Press the button in the left or right headphone output to assign to that headphone output channel.
An 'x' is placed in the button.

Invert Phase

When building M+S monitoring phase of one of the channels needs to be inverted. Use the Phase Invert
button to invert the playback phase of any channel. The Deva displays
inverted.
Important: Invert Phase only inverts the playback phase, it does not affect the recorded audio in any way.

Camera Input

The Camera Input button allows you to perform confidence audio monitoring from the camera using the
camera connector on the right side of the Deva. When you enable the Camera Input, you will want to
temporarily disable any other headphone channels being monitored, otherwise you will hear the delayed
audio from the camera on top of those channels.
Note: The Camera Input on the Deva internally sums the camera mix to mono. This summing occurs only on the return
audio, not audio sent to the camera.
35
Get Factory Preset Menu
Chapter 3
indicating the channel is
