Chapter 4______________________________________________________Zaxcom Fusion User's Manual

Enabling the High Pass Filter (Analog/Digital)

Setting the High Pass Filter value

To set the Highpass Frequency, perform the following, on the
{p.80}:
1. Press the High Pass (#) Hz button. You are prompted to enter the highpass frequency in Hz.
2. Enter the frequency using the numeric keys. The valid frequency range is 30 Hz to 240 Hz.
Any value outside this range is placed near the closest valid number within this range.
3. Press High Pass (#) Hz button or the ENTER key to finish entering the Cutoff Frequency.
NOTE: The Cutoff Frequency value last entered is used as the default value for the next Cutoff Frequency.

Setting the High Pass Filter Frequency on Multiple Channels

To copy the Cutoff Frequency from part #1 to the appropriate channels, perform the following on the
Configure page (Analog Inputs selected)
1. Press the High Pass Filter button. The button‟s LED indicator flashes green while it is active.
2. Press the Channel button for the channel to which you want the highpass filter applied.
The HPF indicator on the button changes to the selected Cutoff Frequency.
3. Repeat #2 for each channel you want to change.
4. Once the last channel has been changed, press the High Pass Filter button again. The LED stops flashing.
NOTE: To disable the highpass filter, press the High Pass Filter button on the
Inputs selected)

Enabling 48 VDC Phantom Power (Analog Only)

Some microphones require external power to operate. The Fusion supplies the full power and current allowed by
the phantom power specification (48 VDC up to 1.0 A). The Fusion does not supply 12T power, which is required
by some older microphones. If you use microphones requiring 12T power, check with your local audio dealer for
phantom to 12T power converters.
To enable phantom power, perform the following:
1. Press the Channel button on the
The Analog Input (#) page
2. Press the 48V Off button. The text turns red and changes to 48V On indicating it is active.
IMPORTANT: To protect equipment from damage, the Fusion does not allow you to apply power to any
channel set as a line-level input.

Adjusting the Trim (Analog/Digital)

There are two ways to adjust the input trim on channels. If you have multiple inputs, the
Trim page
adjustments to channels, the trim can be adjusted using the on-screen fader in the

Adjusting the Trim using the Analog/Digital Input Trim page

1. Press the Adjust Trim button on the
The Analog/Digital Input Trim page
2. Press the meter for the channel you want to adjust.
When a channel is activated, Trim: ?? dB changes to
3. Press the Less Gain or More Gain button to adjust the selected channel(s).
4. Repeat steps 2 and 3 for each additional channel, as appropriate.
All Trim settings can be reset to 0 dB by pressing the Clear Trim button. A dialog appears after pressing the
Clear Trim button requesting confirmation that you want to clear all of the trim settings.
NOTE: If all channels are going to be set at the same level, you can save time by changing them at the same time.
Press Select All. Any change made to the level is applied simultaneously to all of the channels.
Pressing either the STOP button in the upper-right corner of the page or using the MENU key exits the
Analog/Digital Input Trim page
selected)
{p.80}, and then press the channel(s) you want to disable.
{p.82} for that channel appears.
{p.103} allows you adjust all of them from a single page. However, if you are making individual
{p.103} and returns you to the
{p.80}.
Input Configure page (Analog Inputs selected)
{p.80}:
Input Configure page (Analog Inputs selected)
Input Configure page (Analog Inputs selected)
{p.103} appears.
Trim: ??
134
Input Configure page (Analog
{p.80}.
Analog/Digital Input
Analog Input (#) page
{p.80}.
dB.
Input Configure page (Analog Inputs
Input
{p.82}.
