SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
108
Screen 2
• Jitter – average error or "wobble" in received packet timing, in
microseconds
• Last successful transmit data rate (LastRate)
• Gateway type (GatewyType)
• TX Power (dBm)
J i t t e r
L a s t R a t e
G a t e w y T y P e
T X P o w e r ( D B m )
Where:
• nnnnn – Jitter in micro-seconds
mmmmm – last transmit rate
•
11Mb – SpectraLink System with SVP Server. Handsets can
—
run at full 11Mb when in 802.11b/g mode
54Mb – SpectraLink System with SVP Server. Handsets can
—
run at full 54Mb when in 802.11a or 802/11g modes
• mnemo – a mnemonic that indicates what type of gateway is
being used
• rrrrr – TX Power configured in dBm
Screen 3
Screen 3 contains a list of the APs that are heard and the following
parameters from each AP:
• Indicator as to whether this is the current AP or an index into the
list of other APs heard (C indicates current)
• Last 2 octets of the MAC address of the AP (mmmm)
• Channel number (ch)
Signal strength (ss)
•
• Either the 802.11 Association ID from the current AP or a
mnemonic for the reason code indicating why the handset didn't
hand off to this other AP
n n n n n
m m m m m
m n e m o
r r r r r
PN: 1725-36038-001-H.doc
