Polycom SpectraLink 8020 Administrator's Manual page 105

PN: 1725-36038-001-H.doc
When the SSID mode is selected, the summary display contains
Any
the first six characters of the APs SSID instead of the beacon interval
as in the example below.
a b 7 b - 2 8
2 a e 5 - 4 8
2 a e 5 - 5 6
M y I D
In (detail) mode the display would appear as follows. The
Detl
left/right arrow keys will move between AP indices.
i : b b b b b b
e e e e e e e e e e e
r r r r r r r r r r r r r + x x x x
Q : X P C : v C
A n y
Where:
• i – index of selected AP (value will be from 0 to 3 inclusive)
bbbbbb – the last three octets of the BSSID for a discovered AP
•
sn – signal strength in –dBm
•
• ch – channel
• bcn – beacon interval
• eeeeeeeeeee – SSID (up to first 11 characters)
• DGHI – standards supported i.e. 802.11d, 802.11g, etc. in addition
to 802.11a and 802.11b.
• rrrrrrrr – rates supported. Basic rates will have a "b" following the
rate
• + – more rates are supported than those displayed
• xxxx – WMM or UPSD if those QoS methods are supported
• Q:XP
o X is a hexadecimal representation of the access categories
configured with admission control mandatory (ACM).
Bit3 = voice, Bit2 = video, Bit1 = background, Bit0 = best
effort. For example, if an AP advertises voice and video as
ACM then X=c. If all the ACs are set as ACM then X=f. If
0 2 A L P H A
0 6 W S M T E S
1 1 v o i c e
D e t l
s n c h b c n
D G H I
s s s s s s s
S m r y
Diagnostic Tools
105
