Loudspeaking Function - ASCOM d81 Messenger User Manual

User Manual
Ascom d81 DECT Handset
6.3.12 Answering a second call during a call
If a second caller calls during a phone call, the handset will beep and display the text
"Incoming call" and the name or phone number of the second caller. To answer the second
caller:
1 Press the soft key Accept.
The text "Switch" briefly appears on screen, and the handset transfers to the second
call. The first call is put on hold.
2 When finished speaking with the first caller, select the "More" soft key.
3 Select "End Call".
The second call is closed and the first call is retrieved.
NOTE: It is possible to reject a second call by pressing the "Decline" soft key instead of the
"Accept" key. The second caller will hear a busy tone, and the call will be logged as a rejected
call in the handset.
6.3.13 Switch between Calls
Prerequisite, a new call has been started during conversation, see
during Conversation
1 Press "More" during the call.
2 Select "Switch".
3 Press "Select" to switch to the other call. The first call is on hold.
If needed, repeat the steps above to switch between the calls.
6.3.14 DTMF
Some systems/PBXs require that the handset sends Dual Tone Multi Frequency (DTMF)
when pressing the keys. DTMF can be enabled as follows:
1 Press the soft key "More" during the call.
2 Select "DTMF".
3 Press "Select". This will enable the use of DTMF.
Tip: It is also possible configure the handset to send DTMF when pressing
releasing
6.3.15 DECT Info
This submenu is only visible if the Admin menu is activated. See handset's Configuration
Manual.
6.4

Loudspeaking Function

There are several options to activate the loudspeaking function:
• Press a Navigation key, Hot key or Soft key defined as short cut to a "Phone call
function. When pressing the key, a predefined number is called, see
page 62.
• When receiving a call, press the left soft key
• During a call, press the left soft key
08 June 2012 / Ver. D
on page 38.
. See the handset's Configuration Manual.
6.3.5 Start a New Call
5
.
6
.
TD 92644EN
and pressing/

"
8.6 Short Cuts on
40
