ASCOM d81 Messenger User Manual page 76

User Manual
Ascom d81 DECT Handset
8 Press "OK". It will now search for a Bluetooth barcode reader for connection.
9 When Bluetooth barcode reader is found, press "Pair".
10 If needed, enter PIN code, see user manual for the Bluetooth barcode reader. Press
"OK".
The dialog Successful pairing appears if the pairing process was successful. The
Bluetooth barcode reader will also be connected indicated by the icon
the barcode reader.
8.8.2 Headset
In order to achieve optimal audio quality with the different headset types, it is
recommended to select the corresponding headset type.
The default setting is microphone on a boom, that is, the audio is optimized for using a
headset with microphone on a boom. The headset type can be changed in the menu by
doing as follows:
1 Enter the menu by pressing "Menu".
2 Select
3 Select "Headset".
4 Select the corresponding headset type from list, that is, "Mic on boom", or "Hearing
protection". Additional headsets
5 Press "Select".
Tip: It is possible to configure the headset button with a specific function, such as post-dial,
dial last called number, or dial a predefined number. See the handset's Configuration Manual
for more information.
Note: When Bluetooth is disabled and having an active call in loudspeaker mode on an
intrinsically safe handset, the audio will not be transferred to the headset when connecting
it.
IMPORTANT: The headset Microphone on a boom is not available as accessory for the
intrinsically classified handset. If used, it is NOT permitted to use the headset in hazardous
areas.
8.8.3 System
The handset can subscribe up to eight different systems.
Change System
Select "Automatic" or a specific system. If the handset is set to "Automatic", it selects a
system according to the priority list, see
Subscribe IP-DECT System (Release 4.x or higher)
A handset can subscribe to an IP-DECT system automatically if the following are fulfilled:
• The IP-DECT system is configured for Easy Registration, see Installation and Operational
Manual, IP-DECT, TD 92579GB.
• The handset's extension number and IPEI are registered in the IP-DECT system, see the
corresponding manual for the IP-DECT system.
• The handset is not subscribed to any systems.
22.Only visible if a headset profile has been configured in the PDM/Device Manager.
08 June 2012 / Ver. D
in the menu.
22
might be visible in the list.
Priority on page 74.
TD 92644EN
in front of
72
