ASCOM d81 Messenger User Manual page 16

User Manual
Ascom d81 DECT Handset
1
2
3
4
5
6
7
1.Applicable for the d81 Protector only.
2.Applicable for the d81 Protector with the hardware variant Man-down and No-movement only.
08 June 2012 / Ver. D
19 1
18
17
16
15
14
13
12
11
10
1
Push button
The button is placed on the top side of the handset. The Push button is
used for sending alarms, see
Earpiece speaker
2
Pull cord connector
Is used for connection of the pull cord to the handset, see also
Cord Alarm on page 43.
Colour display
The full graphic type display is 128 pixels wide and 160 pixels high.
The display has multiple colours and backlighting.
Four-way navigation key
Use this key to step in the menu and when working in text mode. , ,
, and are used for stepping left/right and up/down in the menu.
The navigation key can be programmed, the
cut to the Inbox, and is a short cut to Call contact. See also
Define Navigation Key on page 63. During a call it is possible to
increase/decrease the volume by pressing
On-hook and On/Off key
Combined button; to end a call, to return to idle mode, and to switch
the handset on/off by long press.
Tactile indicators
There are two tactile indicators to indicate the centre of the key pad
2
3
4
5
6
7
8
9
7.1 Push-Button Alarm on page
is by default a short
and .
TD 92644EN
42.
7.3 Pull-
8.6.3
12
