ASCOM d81 Messenger User Manual page 101

User Manual
Ascom d81 DECT Handset
A.4 Headsets
A number of Bluetooth headsets for different work situations have been tested together
with the handset. Refer to the Ascom Wireless Extranet Website for a list of verified
Bluetooth headsets.
Since the Bluetooth supports the Bluetooth 2.0 standard, other headsets may also work
although not verified by Ascom.
Note: Your Bluetooth headset may have more or less functions than described here, refer to
the Manual for the Bluetooth headset.
A.5 Operation
A.5.1 Enable Bluetooth
To enable the Bluetooth function enter
select "Enable".
Note: When enabling Bluetooth on an intrinsically safe handset, it will be restarted.
A.5.2 Pair and Connect a Bluetooth Headset
Before a headset can be used, a connection (pairing) between the headset and the handset
must be established.
1 Place the Bluetooth headset and the handset next to each other.
2 Enable Bluetooth, see
3 Put the Bluetooth headset in pairing mode, see the user manual for the Bluetooth
headset.
4 Enter the menu by pressing "Menu".
5 Select
6 Select "Bluetooth".
7 Select "Headset".
8 Select "Add new". An information text "Put headset in Pairing mode" is displayed.
9 Press "OK". It will now search for a Bluetooth headset for connection.
10 When headset is found, press "Pair".
11 If needed, enter PIN code, see user manual for the Bluetooth headset. Press "OK".
The dialog Successful pairing appears if the pairing process was successful. The
Bluetooth headset will also be connected indicated by the icon
headset.
Tip: It is possible to configure the headset button with a specific function, such as post-dial,
dial last called number, or dial a predefined number. See the handset's Configuration Manual
for more information.
08 June 2012 / Ver. D
Step between the menus with the navigation key. Confirm each menu
selection by pressing the Soft key "Select".
A.5.1 Enable
in the menu.
in the handset menu, select "Bluetooth" and
Bluetooth.
TD 92644EN
in front of the
97
