5.4 Error Code
5.4.1 Outline

5.4.1.1 Error Code Outline

An error code is used to indicate a fault in a machine, and is indicated in the machine's LCD or reports, showing the nature (symptoms) of the fault. Using the error
code, the user or the service man can readily find out how to correct the fault by simply referring to the User's Manual or service manual.
An error code may be either of the following two types:
User Error Codes
A fault indicated as a user error code is one that can easily be corrected by the user, as by operating the machine. It takes the form of "#+number."
Service Error Codes
If a fault calls for a service man for correction, it is indicated as a service man error code in the form of "##+number" or "SYSTEM ERROR E+number."
Memo
A service error code expressed in the form of "##+number" will not appear on the LCD, Error Tx Report, or Activity Report while the machine remains
in factory default state. To check a service error code, shift bit 0 of service soft switch #1 SSSW SW01 to '1'.

5.4.1.2 Service Error Code

The descriptions on service error codes in this Manual are limited to "SYSTEM ERROR E + numeral."
For descriptions on "## + numeral," see the separately available G3/G4 Facsimile Error Code Service Handbook.
The following is a list of service error codes (SYSTEM ERROR E + numeral):
Code
E000
E001
E002
JNCU1
JNCU2
JLBP1
J3
J101
J1
J125
J127
J4
J23
J2
J5
J6
J401
Main cause/description
fixing assembly faulty start-up (open circuit
in the main thermistor)
fixing assembly faulty start-up (open circuit
in the sub thermistor)
fixing assembly faulty start-up (open circuit
in the fixing heater)
fixing heater overheating (short-circuit in
the main thermistor)
fixing heater overheating (short-circuit in
the sub thermistor)
fixing assembly low temperature (open
circuit in the main thermistor)
fixing assembly low temperature (open
circuit in the sub thermistor)
fixing assembly low temperature (open
circuit in the fixing heater)
JPSU1
JBAT2
JBAT1
J1
CCD
J3
J3
J1
J8
J10 CN1
J1
CN105
J712
J202
J203
J201
J301
J205
J204
F-5-7
T-5-3
Remedial action
Check the connector of the fixing film unit.
Replace the fixing film unit.
Replace the DCNT Borad PCB.
Check the connector of the fixing film unit.
Replace the fixing film unit.
Replace the DCNT Borad.
Check the connector of the fixing film unit.
Replace the fixing film unit.
eplace the DCNT Borad.
J4
J13
J21
CN2
