Icom IC-FR5000 Series Sales Handbook page 49

Regional Trunking System
Antenna
Combiner
Network
Management
Control Room
This is a plan to upgrade to a site linked regional
trunking system.
System requirement (One site) System requirement (One site) System requirement (One site) System requirement (One site)
Descriptions
UHF Repeater
Channel Module Unit
UHF Antenna
Antenna Combiner
Channel Controller
System Control IF
PC
Management Software
Regional PCM Switch
Regional Controller
PSTN/PABX or T1/E1
MPT1327 Trunking System
Local Site
IC-FR6000 + UR-FR6000
IC-FR6000
Channel
Controller
RS-232C
System Control
Interface
Regional
PCM Switch
Regional
Controller
Audio
Site Link Unit
Data
Model Number Quantity
IC-FR6000
UR-FR6000
Regional Site 1
Regional Site 2
PSTN or
Regional Site 3
T1/E1
49
