Note: Operation of the functions described below may depend on repeater programming.
❶ INTERNAL SPEAKER INTERNAL SPEAKER
INTERNAL SPEAKER INTERNAL SPEAKER
Monitors received signals.
❷ VOLUME CONTROL [VOLUME] VOLUME CONTROL [VOLUME]
VOLUME CONTROL [VOLUME] VOLUME CONTROL [VOLUME]
Adjusts the audio output level.
❸ SELECTOR DIAL [SELECT] SELECTOR DIAL [SELECT]
SELECTOR DIAL [SELECT] SELECTOR DIAL [SELECT]
Rotate to adjust the squelch threshold level, select
the operating channel. (Depending on the pre- the operating channel. (Depending on the pre-
programmed condition.)
❹ POWER INDICATOR [POWER] POWER INDICATOR [POWER]
POWER INDICATOR [POWER] POWER INDICATOR [POWER]
➥ Lights green at 'A' module's indicator while the
repeater power is turned ON.
When a channel extension module is installed: When a channel extension module is installed: When a channel extension module is installed: When a channel extension module is installed:
➥ Light green at the selected module indicator ('A'
or 'B') while the repeater power is turned ON.
➥ Lights orange at the un-selected module indicator
('A' or 'B') while the repeater power is turned ON.
❺ TRANSMIT INDICATOR [TX] TRANSMIT INDICATOR [TX] TRANSMIT INDICATOR [TX] TRANSMIT INDICATOR [TX]
Lights red while transmitting.
❻ BUSY INDICATOR [BUSY] BUSY INDICATOR [BUSY] BUSY INDICATOR [BUSY] BUSY INDICATOR [BUSY]
Lights green while receiving a signal or when the
noise squelch is open.
▒ About [PWR], [TX] and [BUSY] indicator: About [PWR], [TX] and [BUSY] indicator:
About [PWR], [TX] and [BUSY] indicator: About [PWR], [TX] and [BUSY] indicator:
▒ 'A' and 'B' modules indicators are available for
▒ these indications. 'A' module's indicator corresponds
▒ to the original module, and 'B' module's indicator
▒ corresponds to an extended module.
4

Operation and Function

4-1

Panel Description

❼ MICROPHONE/SPEAKER CONNECTOR [MIC/SP] MICROPHONE/SPEAKER CONNECTOR [MIC/SP]
MICROPHONE/SPEAKER CONNECTOR [MIC/SP] MICROPHONE/SPEAKER CONNECTOR [MIC/SP]
This 8-pin modular jack accepts the optional
microphone.
▒ KEEP KEEP KEEP the [MIC] KEEP [MIC] connector cover attached to the [MIC] [MIC]
▒ repeater when the optional microphones is not
▒ used.
_______________________________________________________________ _______________________________________________________________
➀+8 V DC output (Max. 15 mA)
➁I/O port for PC programming
➂NC
➃M PTT (Input port for TX control)
➄Microphone ground
➅Microphone input
➆Ground
➇M MONI (Input port for monitor control)
______________________________________________________________________________________________________________________________________________________________
❽ POWER SWITCH [POWER] POWER SWITCH [POWER] POWER SWITCH [POWER] POWER SWITCH [POWER]
➥ Push to turn the repeater power ON.
➥Push and hold for 3 sec. to turn the repeater
power OFF.
When a channel extension module is installed: When a channel extension module is installed: When a channel extension module is installed: When a channel extension module is installed:
➥ While the repeater power is turned ON, push to
select the desired module to operate the repeater
as the base station.
• The power indicator of the selected module unit
lights green.
❾ DEALER DEALER- - - - PROGRAMMABLE KEYS DEALER DEALER PROGRAMMABLE KEYS PROGRAMMABLE KEYS PROGRAMMABLE KEYS
Desired functions can be programmed independently
by your dealer.
Ask your dealer for details.
• Because these keys are programmable, the
functions of these keys are unique to each unit.
