Digital - - - - Analog / Analog
Digital
Digital
Digital
Analog / Analog - - - - Analog Cross mode connection
Analog / Analog
Analog / Analog
• Analog TX signal can be RX by Analog/Digital radios
• Digital TX signal can be RX by Analog/Digital radios
• Repeater/Digital radio operate in Mixed-Digital mode
• Analog radio operates in Analog mode
• Analog repeater for Analog TX only
TX Antenna 1
Tx = f
CTCSS
Tx = f
1
Rx = f
2
CTCSS
Analog H/H
Analog H/H
Analog modulated signal from analog area
Digital modulated signal from digital area
Analog modulated signal from digital area
Frequency
Frequency
Frequency
Frequency
f
: Uplink (both Digital & Analog)
1
f
: Analog Downlink
2
f
: Digital or Analog Downlink
3
This is an example of Digital and Analog cross mode
operation. The IDAS radio (including repeater) can
receive both analog mode and digital mode signals on
a single channel. This function is useful when
introducing digital system components into an existing
analog system. It allows the system operator to
communicate with analog only terminals while utilizing
the digital features as required.
System requirement (One site)
System requirement (One site)
System requirement (One site)
System requirement (One site)
Descriptions
UHF Repeater
IC-FR6000
UHF RF Module
UR-FR6000
TX Antenna
RX Antenna
Multi Coupler
Interface Cable
25p to 25p
5-2
Digital-Analog Cross System
Analog Cross mode connection
Analog Cross mode connection
Analog Cross mode connection
2
IC-FR6000 + UR-FR6000
Model Number
Quantity
RX Antenna
Rx = f
1
Linking
interface
Connection example
Connection example
Connection example
Connection example
Connect two repeaters by interface cable (25p to 25p).
These interface cables are not sold as Icom accessories,
therefore please assemble the interface cable by
yourself. The connection diagram is as follows;
Analog Repeater (25pin)
Pin Description
Pin No.
MODIN
8
EPTT
19
EPTT
19
GND
7,14
EPTT
P19
Resistor 47kΩ
GND
P7,14
TX Antenna 2
Tx = f
3
(25pin)
Tx = f
1
Rx = f
3
Digital H/H
Digital H/H
Digital Repeater (25pin)
Pin No.
Pin Description
22
AFOUT
⇔
21
Digital Audible
⇔
23
Analog Audible
⇔
7,14
GND
⇔
Digital Audible
P21
Analog Audible
P23
Switching Diode e.g. MA2C167
GND
P7,14
40
