6. TROUBLESHOOTING PROCEDURES
The scanner is recognized as connected by the operating system (in the Device Manager),
but the message "Scanner not found" is displayed in Scanning Master 21+ and the scanner
cannot be connected.
Cause
The "Model Setup" settings are not
correctly set in Scanning Master 21+.
Is the "Connection Method" of the
Scanning Master 21+ correctly set?

6.3 The control panel's red Error lamp is lit

Cause
A hardware error at the ROM, RAM, etc.
occurred during the scanner's self-test.

6.4 The control panel's red Error lamp is flashing

Cause
The scanner was turned on with a docu-
ment left loaded inside it.
The top cover was opened during a scan-
ning operation or while a document
was left in the scanner.
If the document becomes jammed.
The document length setting made in
Scanning Master 21+ is longer than the
length of the actual document.
6 – 2
Remedy
Set the "Model Setup" settings in Scanning
Master 21+ to "CS500 series or IS200 series."
For details, refer to the Scanning Master 21+
User's manual.
Ensure that the "Connection Method" of the
Scanning Master 21+ is set to "USB" when you
are using a USB interface. Consult the
Scanning Master 21+ user's manual for further
information.
Remedy
An internal error has occurred. Contact your
sales representative or nearest Graphtec vendor.
Remedy
Open the cover and remove the document (see
Section 5.5, "Removing a Jammed Document").
Press the control panel's STOP button to cancel
the error state. Next, remove the document by
pressing the FORWARD/REVERSE button to
advance the document.
Open the cover and remove the document.
Refer to Section 5.5, "Removing a Jammed
Document."
The scanner's Error lamp flashes when the end
of the document is reached, but this does not
indicate a problem with the scanner itself.
Follow the Scanning Master instructions.
