4. LOADING A DOCUMENT

This chapter describes the document types compatible with your scanner and procedures
related to loading a document.

4.1 Compatible Document Types

Because the scanner scans a document while feeding it, the document types that it can
scan are subject to the following restrictions.
Compatible Media Widths for Scanning
Documents with a maximum width of 1066 mm
Size
A4 210 mm × 297 mm
A3 297 mm × 420 mm
A2 420 mm × 594 mm
A1 594 mm × 841 mm
A0 841 mm × 1189 mm
Compatible Media Lengths for Scanning
Documents up to approximately 16 m in length (driver software limitation) can be scanned.
However, the actual document length that can be scanned is limited by the available
memory (hard disk or other data storage device) of the computer to which the scanner
is connected, and also by the grade of the medium being scanned.
Compatible Grades & Thickness for Scanning
Media Grades
The scanning precision is guaranteed for high-grade tracing paper (see APPENDIX B,
"SPECIFICATIONS").
Other compatible media types are listed below.
High-grade paper : 60 g/m
Tracing paper
Mylar
Copy paper
Diazo photo-sensitive paper
Media Thicknesses
Observe the following points when scanning a thick medium.
• The CS500/IS200 seris scanners cannot scan a document that is thicker than 1.5 mm.
• When using the carrier sheet, ensure that the combined thickness of both the document
and carrier sheet does not exceed 1.5 mm.
• The carrier sheet alone is 0.2 mm thick.
CS500/IS200
ISO
2
2
: 50 to 55 g/m
: 50 µ m
Size ANSI
A 8.5 in × 11 in
B 11 in × 17 in
C 17 in × 22 in
D 22 in × 34 in
E 34 in × 44 in
