CHAPTER 3 LOADING A DOCUMENT

3.1 Compatible Document Types

Because the scanner scans a document while feeding it, the document types that it can scan are
subject to the following restrictions.

Compatible Media Widths for Scanning

Documents with a maximum width of 965 mm
Size
A
B
C
D
E1
E
Size
A4
A3
A2
A1
A0
Size
A4
A3
A2
A1
A0

Compatible Media Lengths for Scanning

Length can be set up to 999.99999 m.
Long documents might be unreadable depending on the connected computer's environment.

Compatible Document Thicknesses for Scanning

The CSX510-09/CSX530-09/CSX550-09 cannot scan a document that is thicker than 1.6 mm.
When using the carrier sheet, ensure that the combined thickness of both the document and carrier
sheet does not exceed 1.6 mm.
Moreover, documents of an uneven thickness cannot be scanned.
Note: The carrier sheet alone is 0.2 mm thick.
ANSI Architectural
9 x 12 in
12 x 18 in
18 x 24 in
24 x 36 in
30 x 42 in
36 x 48 in
DIN
9.44 x 12.99 in
12.99 x 17.71 in
17.71 x 24.60 in
24.60 x 34.64 in
34.64 x 48.42 in
JIS (ISO)
210 x 297 mm
297 x 420 mm
420 x 594 mm
594 x 841 mm
841 x 1189 mm
Size ANSI Engineering
A
B
C
D
E
Size
B4 257 x 364 mm
B3 364 x 515 mm
B2 515 x 728 mm
B1 728 x 1030 mm
3-1
8.5 x 11 in
11 x 17 in
17 x 22 in
22 x 34 in
34 x 44 in
JIS (ISO)
