Paper handling

Fanfold paper

A
2-18
Operating the printer
Move the paper select lever forward to
continuous paper position.
If necessary, readjust the Print Gap
lever for continuous forms (see section
"Print Gap Lever" on page 2-17).
Slightly press the single sheet feeder to
the right or to the left, until the holding
pin comes free from its recess. Remove
the feeder.
Release the tractor locking levers
pulling them up. Once the right forms
tractor is positioned, lock it by pulling
up its locking lever.
Raise the tractor doors and fit the first
two paper feed holes onto the right
tractor pins. Close the right tractor
door.
