Cleaning
Open the cover of the printer and the protective cover of the platen and remove the
ribbon cartridge. Using a soft vacuum brush, gently vacuum the platen, the printhead
carriage and shaft, and surrounding areas. You can easily slide the printhead to the left
or right when the power is off. Be careful not to press too hard on the flat ribbon
cable that extends from the printhead carriage.
Protective
cover
Printhead ca-
ble
Re-install the ribbon cartridge (see "Installing the Ribbon Cartridge" on page 5-5).
Remove the single sheet feeder and clean the form tractors and the surrounding
areas.
Single sheet
feeder
Re-install the single sheet feeder.
5-2
Maintenance
