Parallel interface

Parallel Interface Pin Assignment

Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14 nAUTOFEED
15
16
17 Chassis GND
18
B-2
Signal In/Out
nSTROBE In
DATA0 In
DATA1 In
DATA2 In
DATA3 In
DATA4 In
DATA5 In
DATA6 In
DATA7 In
nACK Out
BUSY Out
PE Out
SELECT Out
Out
NC
Signal GND
+5V DC Out
Pin No. Parallel
19 Signal GND
20 Signal GND
21 Signal GND
22 Signal GND
23 Signal GND
24 Signal GND
25 Signal GND
26 Signal GND
27 Signal GND
28 Signal GND
29 Signal GND
30 Signal GND
31 nINIT
32 nERROR
33 Signal GND
34 NC
35 +5V DC
36 nSELECT IN
Interfaces
In/Out
In
Out
Out
In
