Set-Up mode

COMMON (PUSH TRAC) menu

Parameter
PAPER SET
LPI
TOP MARGIN
BOTTOM MARGIN 0/60INCH/1/60INCH
RIGHT MARGIN
FORM LENGTH
CENTERING
4-14
Value
COMMON
FEED DEPEND
1LPI/2LPI/3LPI/4LPI/5LPI Sets the line density in lines per
/6LPI/8LPI/12LPI
0/60INCH/1/60INCH
/...../119/60INCH/
120/60INCH
/...../29/60INCH/30/
60INCH
8 INCHES/13.6 INCHES
3 INCHES/3.5 INCHES/
4 INCHES/5.5 INCHES/
6 INCHES/7 INCHES/
8 INCHES/8.5 INCHES/
11 INCHES/
11 2/3 INCHES/
12 INCHES/14 INCHES/
17 INCHES
MODE1
MODE2
Special mode
Description
Apply paper properties to all
paperways or feed dependend.
inch.
6LPI = 6 lines per inch.
Specifies the position of the top
line in n/60 inch. See "Print Area
Definition" on page 2-25.
Specifies the position of the bot-
tom line in n/60 inch. See "Print
Area Definition" on page 2-25.
Specifies the print width of the
wide model.
Specifies the length of the page in
inches. See "Print Area Definition"
on page 2-25.
Adjusts the position of the print-
head to the used paper width.
This reduces and optimizes the
printhead movement.
Narrow printer: Select MODE1
for paper widths between 125 and
209 mm and widths narrower as
125 mm.
Wide printer: Select MODE1 for
paper widths narrower as
125 mm. Select MODE2 for
paper widths between 125 and
210 mm.
