Displaying the RMON Configuration
Execute the display command in all views to display the RMON configuration, and
to verify the configuration.
Table 64 Displaying and Debugging RMON
Operation
Display the RMON statistics
Display the history information of RMON
Display the alarm information of RMON
Display the extended alarm information of
RMON
Display the RMON event
Display the event log of RMON
Set an entry in the RMON Ethernet statistics table for Ethernet port performance,
which is convenient for network administrators' query.
Figure 6 RMON Configuration Networking
Console port
Switch
1 Configure RMON.
[SW7700-Ethernet2/0/1] rmon statistics 1 owner 3com-rmon
2 View the configurations in user view.
<SW7700> display rmon statistics Ethernet2/0/1
Statistics entry 1 owned by 3com-rmon is VALID.
Gathers statistics of interface Ethernet2/0/1. Received:
octets
broadcast packets
undersized packets
fragments packets
CRC alignment errors:0
Dropped packet events (due to lack of resources):0
Packets received according to length (in octets):
64 :644
256-511:101
Command
display rmon statistics [ port-num ]
display rmon history [ port-num ]
display rmon alarm [ alarm-table-entry ]
display rmon prialarm [ prialarm-table-entry
]
display rmon event [ event-table-entry ]
display rmon eventlog [ event-number ]
Internet
Network port
: 270149,packets
:1570 ,multicast packets:365
:0 ,oversized packets:0
:0 ,jabbers packets
,collisions
, 65-127 :518
, 512-1023:3
: 1954
:0
:0
, 128-255 :688
, 1024-1518:0
